    Rogue Outcast 2 Beam

    A lightweight, IP65-rated moving head beam fixture that harnesses a powerful 300W lamp to project an intensely bright, tight beam with multifaceted aerial looks from split colors, gobos, and rotating prisms.
    Suited for both indoor and outdoor productions, including tours, festivals, and large-scale events that demand a powerful, weather-resistant fixture for creating cutting aerial beam effects.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: ROGUEOUTCAST2BEAM

    Rogue Outcast 2 Beam

    Specifications
    		 Download
    Rogue Outcast 2 Beam Photometrics Report
    		 Download
    Quick Reference Guide
    		 Download
    DMX Chart
    		 Download
    CAD Files
    		 Download
    User Manual
    		 Download
    Firmware
    		 Download
    Download All Resources

    Rogue Outcast 2 Beam

    SKU: ROGUEOUTCAST2BEAM

    Rogue Outcast 2 Beam projects intensely bright and tight beams from a lightweight IP65 moving head designed to harness the power of its 300W 8000K lamp to slice through atmospherics and outshine any other effect. Aerial looks are sharp and multifaceted with split colors, stunning gobos, layerable rotating prisms and precision focus. Apply frost for even light distribution. Reduce maintenance with a durable alloy body built to withstand the elements, inside or out.

    Features

    High-Powered Beam Fixture

    A fully featured fixture powered by a long-lasting Ushio 300W lamp with an 8,000-hour life expectancy.

    IP65 Rated Housing

    Features a lightweight aluminum and magnesium housing with an IP65 rating for protection against the elements.

    Dual Layerable Prisms

    Create stunning visual impact with individually controllable and layerable 5-facet linear and 8-facet round prisms.

    Frost Filter

    Includes a frost effect for producing an even light distribution and soft-edge looks.

    Tight Beam Angle

    Produces a razor-sharp 0.8° narrow beam for highly focused aerial effects with no field spill.

    Static Gobo Wheel

    Offers a wide array of 17 static gobos for creating massive visual effects.

    Flexible Protocol Control

    Supports both DMX and RDM protocols for comprehensive remote control and management.

    Professional Power Input

    Equipped with a True 1 compatible power input for secure and reliable connections.

    Onboard OLED Display

    Features an easy-to-read OLED display with a simple menu for effortless fixture setup.

    Versatile DMX Profiles

    Provides both simple and complex DMX channel profiles to suit any programming style.

    USB-C Software Port

    Allows for easy software uploads and updates via a convenient USB-C port.

    Latest News

    Zalight and CHAUVET Professional Help Nicolò Damiani of MG Service Accent Beauty of Tones Teatro Natura
    Nicolò Damiani accents a former quarry’s natural beauty with light for a stunning orchestral performance in Italy.
    Read more
    Zalight and CHAUVET Professional Help Nicolò Damiani of MG Service Accent Beauty of Tones Teatro Natura
    Nicolò Damiani accents a former quarry’s natural beauty with light for a stunning orchestral performance in Italy.
    Read more
    More Related News

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Optical

      • Light Source

        300W NSL Ushio lamp, 8000 K (color temp), 8,000 hours life expectancy

      • Color Temperature (at full)

        7353 K

      • Front lens diameter

        160 mm

      • CRI

        75.5

      • Beam Angle

        0.8°

      • Field Angle

        1.6°

      • Cutoff Angle

        2°

      • Lumens – Output

        29,130

      • Illuminance (total)

        204,855 lux @ 15 m

      Dynamic Effects

      • Pan and Tilt

        540°/260°

      • Pan and Tilt Ranges

        540°, 360°, 180° pan/260°, 180°, 90° tilt

      • Colors

        14 + white, split colors, continuous scroll at variable speeds

      • Gobos

        17 + open (17 metal), 17 static, continuous scroll at variable speeds; size: 106 mm (outside), 6 mm (image), 0.6 – 0.8 mm (max. thickness)

      • Dimmer

        Electronic

      • Shutter/Strobe

        Motorized

      • Focus

        Motorized

      • Frost

        Motorized

        • Prism
          • Detail

            5 Facets, motorized, rotating

          • Detail 2

            8 Facets, motorized, rotating

      • Move-in-Black

        Yes

      Construction/Physical

      • Dimensions

        14.41 x 9.61 x 22.6 in (366 x 244 x 574 mm)

      • Weight

        45.19 lb (20.5 kg)

      • Exterior Color

        Black

      • Housing Material

        Aluminum/Magnesium diecast

      Connections

      • Power Connection

        Edison plug to Seetronic Powerkon IP65

      • Power Input

        Seetronic Powerkon IP65

      • Data Connectors

        5-pin IP rated

      • Cable Length (power)

        5 ft (1.5 m)

      Control

      • Control Protocol

        DMX, RDM

      • DMX Channels

        16 or 18

      • Modes/Personalities

        2 personalities (16, 18)

      Electrical

      • Input Voltage

        100 to 240 VAC, 50/60 Hz (auto-ranging)

      • Power and Current

        413 W, 3.51 A @ 120 V, 60 Hz

      • Power and Current

        403 W, 2.01 A @ 208 V, 60 Hz

      • Power and Current

        404 W, 1.82 A @ 230 V, 50 Hz

      Certifications/Qualifications

      • Certifications

        CE, MET, UKCA

      • IP Rating

        IP65, temporary outdoor/ wet, with pressure equalizing M12 GORE valve

      • Temperature (Ambient)

        -14 °F to 113 °F (-10 °C to 45 °C)

      • Maximum Exterior Surface Temperature (Tc)

        80° C / 176° F

      • Maximum Ambient Temperature (Ta)

        45° C / 113° F

      Compatible Accessories

      • Clamps
      • IP65 5 pin DMX Cables
      • IP65 PowerKon Extension cables
      • Flight Case

      What's Included

      • Rogue Outcast 2 Beam
      • Seetronic Powerkon IP65 power cord
      • (2) Omega brackets with mounting hardware

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Photometrics
      Rogue Outcast 2 Beam Photometrics Report
      		Download
      Manuals
      Rogue Outcast 2 Beam – Quick Reference Guide
      		Download
      DMX
      Rogue Outcast 2 Beam – DMX Chart
      		Download
      Drawings
      Rogue Outcast 2 Beam – CAD Files
      		Download
      Manuals
      Rogue Outcast 2 Beam – User Manual
      		Download
      Other
      Rogue Outcast 2 Beam – Firmware
      		Download

      Learn How To Use Your Rogue Outcast 2 Beam

      Explore these detailed videos showcasing setup, features, and creative applications for this product.

      • Rogue Outcast 3 Spot • Rogue Outcast 2 Beam • Rogue Outcast 2 Hybrid

        Meet the Rogue Outcast family from CHAUVET Professional, a series of lightweight, IP65-armored moving heads. This versatile lineup of spot, beam, and hybrid fixtures delivers rugged, low-maintenance performance for any tour or festival, empowering you to create bold looks that can hang anywhere and withstand the elements.

      Video Library

      Rogue Outcast 2 Beam FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the Rogue Outcast 2 Beam
      Can the Rogue Outcast 2 Beam be used outdoors in the rain?

      Yes. The Rogue Outcast 2 Beam is specifically designed with a durable, weatherproof body to withstand the elements. This makes it a reliable choice for outdoor festivals, concerts, and events, as it can operate safely even in wet conditions.

      What kind of lighting effects can the Rogue Outcast 2 Beam create?

      It excels at creating intensely bright, tight beams of light that are perfect for stunning mid-air effects. You can add visual texture using a wheel of built-in patterns, split the beam into different colors, or multiply the light using two separate rotating prisms which can be layered for more complex looks.

      What makes the Rogue Outcast 2 Beam’s light so sharp and powerful?

      The fixture uses a very powerful lamp to produce an incredibly bright, focused beam designed to cut through fog or haze and remain visible over long distances. It also includes a precision focus feature to keep patterns and aerial effects crisp and clear, no matter the distance.
