COLORdash Batten-Quad 12

The COLORdash Batten-Quad 12 is a versatile linear wash fixture featuring twelve individually controllable RGBA LEDs for creating rich, saturated colors, a full spectrum of whites, and dynamic pixel-mapping effects.
Its flexible mounting options make it ideal for theatrical productions, concert touring, and architectural installations requiring powerful wall-washing or uplighting.

COLORdash Batten-Quad 12

Specifications	Download
COLORdash Batten-Quad 12 Quick Reference Guide	Download
COLORdash Batten-Quad 12 User Manual	Download
COLORdash Batten-Quad 12 DMX Chart	Download
COLORdash Batten-Quad 12 CAD	Download
COLORdash Batten-Quad 12 ShowXpress Profile	Download
COLORdash Batten-Quad12-IES Files	Download
COLORdash Batten Quad 12 Photometrics Report	Download
Firmware	Download

Download All Resources

Getwell Road United Methodist Expands Reach With CHAUVET Professional

COLORdash Batten-Quad 12 is a linear wash fixture with 12 individually controllable quad-colored RGBA LEDs that produce any variation of white as well as richly saturated colors due to the inclusion of amber LEDs. It pixel maps beautifully when used in multiples because it maintains an even pixel pitch. Setup is easy with a hanging bracket, floor trunnions, secure Neutrik® powerCON® power in and out, and 3- and 5-pin DMX connections.

Features

Versatile Control Modes

Access built-in automatic and custom programs using DMX or Master/Slave configurations.

Durable Metal Construction

The all-metal housing provides enhanced durability for reliable, long-term use.

Individual Pixel Control

Each light source can be controlled independently for creating dynamic animations and pixel-mapping effects.

Silent Flicker-Free Operation

Operates quietly and without flicker, making it ideal for on-camera use and noise-sensitive environments.

Seamless Unit Linking

Mount multiple fixtures end-to-end or in a stack to create larger displays with a consistent pixel pitch.

Specifications

Download Product Specs

Optical

Light Source

12 LEDs (quad-color RGBA) 7 W, (500 mA), 50,000 hours life expectancy
Color Temperature (range)

2,800 to 10,000 K
Installed Optics

20°
Beam Angle

22°
Field Angle

31°
Illuminance

539 lux @ 5 m
PWM Frequency

600 Hz

Dynamic Effects

Dimmer

Electronic
Shutter/Strobe

Electronic
Strobe Rate

0 to 20 Hz
Standalone Color Mixing

Yes
Color Temperature Presets

Yes
Dim Modes

4
Built-in Automated Programs

Yes

Construction/Physical

Dimensions

41 x 3.2 x 6.5 in (1041 x 82 x 164 mm)
Weight

10.6 lb (4.8 kg)
Exterior Color

Black

Connections

Power Connection

Edison plug to Neutrik powerCON
Power Input

Neutrik powerCON
Power Output

Neutrik powerCON
Data Connectors

3- and 5-pin XLR
Cable Length (signal)

5 ft (1.5 m)

Control

Control Protocol

DMX
DMX Channels

4, 6, 10, 48 or 52
Modes/Personalities

5 personalities (4CH, 6CH, 10CH, 48CH, 52CH)

Electrical

Input Voltage

100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking

7 units @ 100 V; 9 units @ 120 V; 15 units @ 208 V; 16 units @ 230 V; 16 units @ 240 V
Power and Current

100 W, 1.51 A @ 100 V, 60 Hz
Power and Current

98 W, 1.28 A @ 120 V, 60 Hz
Power and Current

96 W, 0.788 A @ 208 V, 60 Hz
Power and Current

95 W, 0.743 A @ 230 V, 50 Hz
Power and Current

95 W, 0.709 A @ 240 V, 50 Hz

Certifications/Qualifications

Certifications

CE, MET
IP Rating

IP20, dry location

Compatible Accessories

Professional Clamps: CTC-50HC, CTC-50HCN
Neutrik powerCON cables
3-pin or 5-pin DMX Cables

What's Included

COLORdash Batten-Quad 12
Neutrik® powerCON® power cord
2 Trunnions

Questions or Concerns?

Let us know, we’re here to help! Contact Us

Downloads

Download All

Manuals	COLORdash Batten-Quad 12 Quick Reference Guide	Download
Manuals	COLORdash Batten-Quad 12 User Manual	Download
Manuals	COLORdash Batten-Quad 12 DMX Chart	Download
Manuals	COLORdash Batten-Quad 12 CAD	Download
Manuals	COLORdash Batten-Quad 12 ShowXpress Profile	Download
Photometrics	COLORdash Batten-Quad12-IES Files	Download
Photometrics	COLORdash Batten Quad 12 Photometrics Report	Download
Other	COLORdash Batten-Quad 12 – Firmware	Download

Latest Articles

Browse Articles

COLORdash Batten-Quad 12 FAQ’s

Quickly find answers to common questions about setup, operation, and features of the COLORdash Batten-Quad 12

What kind of colors can the COLORdash Batten-Quad 12 produce?

The COLORdash Batten-Quad 12 uses special quad-color LEDs that include an amber element. This allows it to create not only vibrant, saturated colors but also a wide spectrum of high-quality white light, from very warm to cool tones, making it perfect for creating any mood.

How do you create effects with the COLORdash Batten-Quad 12?

Each of the 12 LEDs on the light bar can be controlled independently. This allows you to create dynamic visual effects, like colorful chases and animated patterns. You can also link multiple units together end-to-end to create a longer, seamless line of light for larger displays.

Where is the COLORdash Batten-Quad 12 typically used?

It’s a versatile fixture ideal for washing walls, stages, and backdrops with smooth, even color. It comes with both floor stands and a hanging bracket, so it can be easily placed on the ground or mounted overhead. Its silent, flicker-free operation also makes it perfect for quiet settings like theaters or for on-camera video productions.
