Ovation Rêve F2
Ovation Rêve F2 is a Fresnel designed to deliver soft-edged washes with high-quality color and strong output. Its RGBCAM Rêve color engine produces clean whites and rich colors, while a wide zoom range lets designers adapt beam size to the position and scene. Careful noise management helps keep the fixture unobtrusive during quiet moments.
-
RGBCAM Fresnel with exceptional color quality and output
-
Improved “Rêve” engine with updated features and look
-
Exceptional zoom range and noise management
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
Ovation Rêve F2
Ovation Rêve F2 is a Fresnel designed to deliver soft-edged washes with high-quality color and strong output. Its RGBCAM Rêve color engine produces clean whites and rich colors, while a wide zoom range lets designers adapt beam size to the position and scene. Careful noise management helps keep the fixture unobtrusive during quiet moments.
Its lightweight carbon-fiber composite housing simplifies rigging and handling, and the easy-adjust bracket also found on Ovation Rêve F-3 makes positioning quick and straightforward. Updated on-board controls support efficient setup. As the mid-range option in the Rêve Fresnel lineup, Ovation Rêve F2 offers a versatile balance of output and size and works alongside Rêve ellipsoidals, PARs, house lights and moving head fixtures to help venues build a coordinated color experience from stage to auditorium.
Features
Advanced Rêve Color Engine
The RGBCAM LED array delivers a full spectrum of vibrant colors and clean whites with a high CRI of 97.2 for superior color rendering.
Expansive Motorized Zoom
An impressive 10.5° to 120° motorized zoom range provides incredible versatility, allowing you to create anything from a tight spot to a broad wash.
Flexible And Efficient Control
Streamline your workflow with updated onboard controls, multiple DMX personalities, RDM, and NFC for fast and flexible fixture setup and integration into any system.
Lightweight And Practical Design
A lightweight aluminum die-cast housing and an easy-adjust bracket simplify rigging and handling, making positioning both quick and straightforward for any production.
Specifications
Optical
-
Light Source
1, RGBCAM LED Array
-
Color Temperature (range)
1800 to 10000 K
-
Color Temperature (at full)
5921 K
-
Front lens diameters
196.85 mm
-
CRI
97.2
-
Beam Angle
10.5° to 89.4°
-
Field Angle
18.1° to 108.8°
-
Cutoff Angle
27.2° to 105°
-
Zoom Range
10.5° to 120°
-
-
Lumens
-
Lumens (Narrow)
6787 lm
-
Lumens (Wide)
17183 lm
-
Lumens (50%)
12664 lm
-
-
Lumens
-
-
Illuminance
-
Illuminance (Narrow)
6426 lux @ 5 m
-
Illuminance (Wide)
391 lux @ 5 m
-
Illuminance (50%)
1328 lux @ 5 m
-
-
Illuminance
-
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Zoom
Motorized
-
Strobe Rate
0 to 30 Hz
-
Standalone Color Mixing
Yes
-
Color Temperature Presets
Yes
-
Dim Modes
4
-
Dim Curves
4
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
15.26 x 11.88 x 17.64 in (387.51 x 301.80 x 448.10 mm)
-
Weight
18.6 lb (8.43 kg)
-
Exterior Color
Black
-
Housing Material
Aluminum die-cast
-
Accessory Holder/Gel Frame Size
7.5 in (190.5 mm)
Connections
-
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
-
Software Connection
USB
Control
-
Control Protocol
DMX, RDM, NFC
-
DMX Channels
1, 5, 7, 9, 13, 15, 16, 20, HSV,XY Basic, XY Extended
-
Modes/Personalities
11 personalities (1, 5, 7, 9, 13, 15, 16, 20, HSV,XY Basic, XY Extended)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
; 4 units @ 120 V; 7 units @ 208 V; 8 units @ 230 V;
-
Power and Current
347 W, 2.90 A @ 120 V, 60 Hz
-
Power and Current
341 W, 1.65 A @ 208 V, 60 Hz
-
Power and Current
339 W, 1.48 A @ 230 V, 50 Hz
-
Power and Current (resting)
4 W, .12 A @ 100 V, 60 Hz
-
Power and Current (resting)
4 W, .12 A @ 120 V, 60 Hz
-
Power and Current (resting)
4 W, .16 A @ 208 V, 60 Hz
-
Power and Current (resting)
4 W, .14 A @ 230 V, 50 Hz
-
Power and Current (resting)
5 W, .15 A @ 240 V, 50 Hz
-
Fuse
T 5 A, 250 V
-
Max. Output Current
12 A (4 units @ 120 V) (7 units @ 208 V) (8 units @ 230 V)
Battery
-
Battery type
Lithium
-
Rechargeable
No
Certifications/Qualifications
-
Compliance
CE, MET, FCC, CB
-
MET Listing Number
[E113093-1110, E113093-1125]
-
US Safety
[UL 60950-1]
-
Canadian Safety
[CSA C22.2 No. 60950-1]
-
-
Thermal Dissipation
-
Thermal Dissipation @ 120V
819 BTU per hour
-
Thermal Dissipation @ 208V
819 BTU per hour
-
Thermal Dissipation @ 230V
819 BTU per hour
-
-
Thermal Dissipation
-
-
Noise Levels
-
Ambient
## dB level @ 1 m
-
Static
## dB level @ 1 m
-
Max
## dB level @ 1 m (note : Only moving products)
-
Mode
## dB level @ 1 m
-
-
Noise Levels
-
Operating Temperature
-4 °F to 122 °F (-20 °C to 50 °C)
-
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
-
Minimum Distance from Flammable Material to all exterior surfaces of the product
0.2 m
-
Maximum Exterior Surface Temperature (Tc)
70°C
-
Maximum Ambient Temperature (ta) 45° C
-
Minimum Distance from Irradiated Object to the Final Lens of the Luminaire
0.5 m
Required Accessories
- Required Software: Chamsys, QuickQ, DMX Workshop, etc.
- Controller (required): [Drivers, processors, etc.]
- Compatible Mounting Options: [140DX OMEGA BRACKET, M12 BOLT, VELCRO, ETC.]
Compatible Accessories
- Controllers (optional): IRC, FCW, ACW, FCT, FCM
- Clamps
- Barn Doors
- RIGLINK powerKON cables
- RIGLINK etherKON cables
- RIGLINK DMX Cables
- Flight Cases
- Etc.
What's Included
- Ovation Rêve F2
- Seetronic Powerkon power cord
- Gel frame
- Omega bracket with mounting hardware
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Complete Your Rig
Ovation Rêve F2 FAQ’s
The Ovation Rêve F2 supports DMX and RDM via 5-pin XLR connectors for standard lighting control. It also includes NFC capability, allowing for quick fixture setup and configuration directly from a compatible mobile device without needing to power the unit on.
