    Ovation F-915VW

    A high-power, variable white Fresnel-style fixture utilizing a 6-color LED system to project a bright, soft field of high-CRI light with motorized zoom and adjustable color temperature.
    Ideal for theatre and TV studio applications requiring a beautifully soft field of light with superior color rendering and precise temperature control.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: OVATIONF915VW-2

    Ovation F-915VW

    Specifications
    		 Download
    Ovation F-915VW Quick Reference Guide
    		 Download
    Ovation F-915VW Quick Reference Guide- Legacy S…
    		 Download
    Ovation F-915VW User Manual
    		 Download
    Ovation F-915VW CAD
    		 Download
    Ovation F-915VW IES Files
    		 Download
    Ovation F-915VW Photometric Report
    		 Download
    Ovation F-915VW DMX Chart
    		 Download
    Ovation F-915VW DMX Chart- Legacy Software
    		 Download
    Case study: Chapel Off Chapel Gets More Versati…
    		 Download
    Ovation F-915VW ShowXpress
    		 Download
    Ovation F-915VW Specification Sheet
    		 Download
    Download All Resources

    Ovation F-915VW

    SKU: OVATIONF915VW-2

    Ovation F-915VW is a high-power, variable white Fresnel-style fixture that utilizes our unique 6-color LED system. This fixture projects a bright, beautifully soft field of light in nearly any temperature of white with high CRI and CQS making it ideal for theatres and TV studios. Each Color Temperature can be further adjusted for +/- green and a motorized zoom with a 17° – 85° field range allows you to add light where it is needed. The Color Temperature and hue along with zoom and output can be controlled via DMX or on-board dials.

    Features

    Variable White LED Fresnel

    A versatile lighting fixture designed for professional theatre, film, and production applications.

    Soft and Even Light Field

    Produces a consistently soft and uniform field of light suitable for any scene.

    Motorized Zoom

    Offers a smooth, motorized zoom with a wide beam range from 17° to 85°.

    Wide Color Temperature Range

    Features adjustable color temperature presets from 2800 K to 8000 K, ensuring high color rendering.

    16-Bit Dimming

    Achieve exceptionally smooth and precise dimming transitions with high-resolution 16-bit control.

    Consistent Light Output

    A proprietary LED engine ensures powerful and consistent output across the entire color temperature range.

    On-Board Control

    Easily adjust color temperature, zoom, and dimming directly on the fixture for quick access.

    Green Adjustment Control

    Fine-tune the green output through either DMX or on-board controls for perfect camera matching.

    Full Color Control

    Utilize the 6-color engine for independent color control when a vibrant splash of color is required.

    Remote Device Management

    RDM capability allows for remote addressing and configuration, adding operational flexibility.

    Adjustable PWM

    Avoid on-camera flickering with adjustable Pulse Width Modulation for broadcast-ready performance.

    Silent Operation

    Operates virtually silently, making it ideal for noise-sensitive studio and theatre environments.

    Latest News

    Cody James and JDI Productions Expand Horizons for Ayla Brown Livestream with CHAUVET Professional
    Designer Cody James trades heavy metal intensity for country nuance in a dynamic livestream.
    Read more
    Hildebrandt Veranstaltungstechnik Balances Looks For Volkswagen Branding Event With CHAUVET Professional
    A balanced lighting design helps launch Volkswagen’s new global showroom concept.
    Read more
    The New Leietheater Looks Forward with CHAUVET Professional
    Belgium’s new Leietheater embraces the future with a versatile, all-LED CHAUVET Professional rig.
    Read more
    Lighting a “Broadcast Campus”
    Life.Church’s new broadcast campus uses over 100 CHAUVET Professional fixtures to create immersive, camera-ready worship experiences.
    Read more
    Sotesa and CHAUVET Professional Bridge Old and New for NTGent
    The historic Royal Dutch Theatre embraces a sustainable future with a versatile Ovation LED rig.
    Read more
    Cody James and JDI Productions Expand Horizons for Ayla Brown Livestream with CHAUVET Professional
    Designer Cody James trades heavy metal intensity for country nuance in a dynamic livestream.
    Read more
    Hildebrandt Veranstaltungstechnik Balances Looks For Volkswagen Branding Event With CHAUVET Professional
    A balanced lighting design helps launch Volkswagen’s new global showroom concept.
    Read more
    The New Leietheater Looks Forward with CHAUVET Professional
    Belgium’s new Leietheater embraces the future with a versatile, all-LED CHAUVET Professional rig.
    Read more
    Lighting a “Broadcast Campus”
    Life.Church’s new broadcast campus uses over 100 CHAUVET Professional fixtures to create immersive, camera-ready worship experiences.
    Read more
    Sotesa and CHAUVET Professional Bridge Old and New for NTGent
    The historic Royal Dutch Theatre embraces a sustainable future with a versatile Ovation LED rig.
    Read more
    More Related News

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Optical

      • Light Source

        89 LEDs (6 red, 15 orange-red, 8 green, 12 blue, 16 royal blue, 32 lime) 3 W, (960 mA), 50,000 hours life expectancy

      • Color Temperature (range)

        2800 to 8000 K

      • CRI

        88-92

      • Beam Angle

        17° to 54°

      • Field Angle

        30° to 85°

      • Zoom Range

        17° to 85°

      • Lumens (30°)

        4,143

      • Lumens (85°)

        6,792

        • Illuminance
          • Illuminance (30°)

            1,748 lux @ 5 m

          • Illuminance (85°)

            414 lux @ 5 m

      • Selectable PWM

        600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

      Dynamic Effects

      • Dimmer

        Electronic

      • Zoom

        Motorized

      • Strobe Rate

        0 to 27 Hz

      • Standalone Color Mixing

        Yes

      • Color Temperature Presets

        Yes

      • Dim Modes

        4

      • Built-in Automated Programs

        No

      Construction/Physical

      • Dimensions

        22.41 x 12.59 x 10.82in (569.44 x 320 x 275 mm)

      • Weight

        18.6 lb (8.5 kg)

      • Exterior Color

        Black

      • Housing Material

        Aluminum alloy, Aluminum die-cast

      Connections

      • Power Connection

        Edison (local) plug to Seetronic Powerkon IP65

      • Power Input

        Seetronic Powerkon IP65

      • Power Output

        Seetronic Powerkon IP65

      • Data Connectors

        3- and 5-pin XLR

      • Cable Length (power)

        5 ft (1.5 m)

      Control

      • Control Protocol

        DMX, RDM

      • DMX Channels

        1, 4, 6, 7, 9, 13, 16 or 19

      • Modes/Personalities

        8 personalities (1, 4, 6, 7, 9, 13, 16, 19)

      Electrical

      • Input Voltage

        100 to 240 VAC, 50/60 Hz (auto-ranging)

      • Power Linking

        5 units @ 120 V; 8 units @ 208 V; 9 units @ 230 V

      • Power and Current

        271 W, 2.3 A @ 120 V, 60 Hz

      • Power and Current

        262 W, 1.433 A @ 208 V, 60 Hz

      • Power and Current

        258 W, 1.209 A @ 230 V, 50 Hz

      Certifications/Qualifications

      • Certifications

        CE, MET, FCC, UKCA

      • IP Rating

        IP20, dry location

        • Temperatures
          • Temperature (startup)

            -4 °F to 113 °F (-20 °C to 45 °C)

          • Temperature (operating)

            -22 °F to 113 °F (-30 °C to 45 °C)

      Compatible Accessories

      • Professional Clamps: CTC-50HC, CTC-50HCN
      • TRUE1 Style Power Extensions Cables
      • 3-pin or 5-pin DMX Cables
      • Color Blending Filters: DF60X1D, DF20D
      • Ovation F 7.5” Barndoor V2
      • Ovation 8″ Pole Operated Yoke

      What's Included

      • Ovation F-915VW
      • Seetronic Powerkon IP65 power cable
      • Gel frame (7.5 in/191 mm accessories)

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Manuals
      Ovation F-915VW Quick Reference Guide
      		Download
      Manuals
      Ovation F-915VW Quick Reference Guide- Legacy Software
      		Download
      Manuals
      Ovation F-915VW User Manual
      		Download
      Drawings
      Ovation F-915VW CAD
      		Download
      Photometrics
      Ovation F-915VW IES Files
      		Download
      Photometrics
      Ovation F-915VW Photometric Report
      		Download
      DMX
      Ovation F-915VW DMX Chart
      		Download
      DMX
      Ovation F-915VW DMX Chart- Legacy Software
      		Download
      Case Studies
      Case study: Chapel Off Chapel Gets More Versatility, Lower Energy Costs With New CHAUVET Professional Rig
      		Download
      Other
      Ovation F-915VW ShowXpress
      		Download
      Other
      Ovation F-915VW Specification Sheet
      		Download

      Ovation F-915VW FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the Ovation F-915VW
      Can the Ovation F-915VW create different shades of white light?

      Yes, its main feature is creating beautiful, high-quality white light. You can easily adjust the color temperature from a warm, candle-like glow to a cool, daylight white. It also allows for fine-tuning to ensure skin tones look completely natural, making it perfect for theater and television.

      What is the motorized zoom on the Ovation F-915VW for?

      The motorized zoom allows you to remotely change the size of the light beam. You can easily adjust it from a tight, focused spotlight to a very wide floodlight to cover a large area. This makes it incredibly versatile for lighting anything from a single performer to an entire stage set.

      Why is the Ovation F-915VW good for TV studios and theatres?

      It’s designed for professional studio and stage environments because it is virtually silent, so it won’t be picked up by microphones. It also provides smooth, flicker-free light that looks great on camera. While it excels at white light, it can also produce a splash of color when needed.
