Ovation Rêve F-3
A motorized, full-spectrum RGBAM fresnel that delivers soft, controllable washes with silent operation and an extended zoom range for impressive reach.
Perfectly suited for camera-sensitive environments like theaters, houses of worship, and television/film sets that demand versatile, high-quality, and silent wash lighting.
-
Delivers superior color rendering with a full-spectrum RGBAM LED engine and an impressive 96 CRI.
-
Provides an extended motorized zoom range from 10.9° to 66.5° for impressive reach and coverage.
-
Features linear color temperature control from 2800 K to 8000 K with +/- green adjustment.
-
On-board control dials offer quick adjustments, while its silent cooling is ideal for studio use.
-
Delivers flicker-free video performance using adjustable PWM and exceptionally smooth 18-bit dimming.
-
An innovative adjustable yoke allows for versatile mounting and positioning in low-clearance areas.
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
Ovation Rêve F-3
Ovation Rêve F-3 is a motorized fresnel incorporating our full spectrum (RGBAM) Rêve light engine. A welcome solution for applications and markets in need of soft controllable washes, Rêve F-3 features virtually silent operation, easy on-board control dials, and an innovative adjustable yoke that allows it to be mounted in low clearance areas. Featuring an optical system designed to answer the call for longer throws with an extended zoom range that can narrow from 60 degrees all the way down to 10 degrees in order to achieve impressive reach. A versatile lighting instrument at home in theaters, houses of worship, on TV and Film sets, as well as the rental and production world. Flawlessly smooth dimming, +/- green adjustment, linear CCT and adjustable Pulse Width Modulation ensure performance that looks as good on camera as it does live.
Features
Full Spectrum LED Fresnel
Provides high-quality, full-spectrum light ideal for theatre, film, and production environments.
On-Board Control Dials
Easily adjust multiple parameters directly on the fixture using three intuitive control dials.
Adjustable Color Temperature
Access a wide range of linear color temperature presets from 2800 K to 8000 K with high color rendering.
Virtual Color Wheel
Replicate popular gel colors digitally with the integrated virtual color wheel.
Precise Color Control
Fine-tune your look with plus/minus green adjustment and emulated red-shift via DMX or on-board controls.
Remote Device Management
RDM capability allows for remote addressing and configuration for added flexibility.
Flicker-Free Operation
Adjust the Pulse Width Modulation (PWM) to eliminate on-camera flicker for clean video recording.
Silent Operation
The virtually silent cooling system is perfect for use in noise-sensitive studio and theatre applications.
High-Resolution Dimming
Achieve exceptionally smooth fades with ultra-smooth 18-bit dimming curves to complement any lighting scheme.
Adjustable Mounting Yoke
An innovative, adjustable yoke allows for easy mounting and positioning in low clearance areas.
USB Software Updates
Keep the fixture’s software current with easy updates via the built-in USB port.
Complete Your Rig
Specifications
Optical
-
Light Source
126 LEDs (22 red, 14 green, 16 blue, 6 royal blue, 28 amber, 40 mint) 5.8 to 8 W, (1.82 A) 50,000 hours life expectancy.
-
Color Temperature (range)
2800 to 8000 K
-
Color Temperature (at full)
5249 K
-
Front lens diameters
210.8 mm
-
CRI
96
-
Beam Angle
10.9° to 66.5°
-
Field Angle
19.3° to 88.5°
-
Cutoff Angle
26.2° to 97.3°
-
Zoom Range
10.9° to 97.3°
-
Lumens (narrow)
6179 lm
-
Lumens (wide)
14302 lm
-
Lumens (50%)
10330 lm
-
-
Illuminance
-
Illuminance (narrow)
5375 lux @ 5 m
-
Illuminance (wide)
539 lux @ 5 m
-
Illuminance (50%)
1858 lux @ 5 m
-
-
Illuminance
-
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Zoom
Motorized
-
Strobe Rate
0 to 30 Hz
-
Standalone Color Mixing
Yes
-
Color Temperature Presets
Yes
-
Dim Modes
4
-
Dim Curves
4
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
15 x 13.5 x 15.7 in (381.4 x 342 x 399.3 mm)
-
Weight
26.2 lb (11.9kg)
-
Exterior Color
Black
-
Housing Material
Aluminum die-cast
-
Accessory Holder/Gel Frame Size
7.8 in (198 mm)
Connections
-
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
3- and 5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
-
Software Connection
USB
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
1, 5, 6, 8, 12, 14ch1, 14ch2, or 18
-
Modes/Personalities
8 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, or 18)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
2 units @ 120 V; 4 units @ 208 V; 5 units @ 230 V
-
Power and Current
528 W, 4.39 A @ 120 V, 60 Hz
-
Power and Current
517 W, 2.52 A @ 208 V, 60 Hz
-
Power and Current
513 W, 2.22 A @ 230 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET, FCC
-
IP Rating
IP20, dry location
-
-
Noise Levels
-
Noise Level (Idle)
4.1 dB(A) @ 1 m
-
Noise Level (Auto)
37.2 dB(A) @ 1 m
-
Noise Level (On)
39.1 dB(A) @ 1 m
-
Noise Level (Off)
6.5 dB(A) @ 1 m
-
Noise Level (Silent)
35.1 dB(A) @ 1 m
-
-
Noise Levels
-
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories
- Professional Clamps: CTC-50HC, CTC-50HCN
- Safety Cable: SC-07
- Ovation F 7.5 Barndoor V2
- TRUE1 Style Power Extension Cables
- 3-pin or 5-pin DMX Cables
- RDM2go
- USB Jump Drive
- Ovation Pole Operated Yoke 2 – 8”
What's Included
- Ovation Reve F-3
- Seetronic Powerkon power cord
- Gel frame holder (7.5 in/191 mm accessories)
- Gel frame
- (1) 140mm Omega bracket with mounting hardware
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
Manuals | Ovation Rêve F-3 – Quick Reference Guide | Download |
Manuals | Ovation Rêve F-3 – User Manual | Download |
DMX | Ovation Rêve F-3 – DMX Chart | Download |
Photometrics | Ovation Rêve F-3 – IES Files | Download |
Photometrics | Ovation Reve F-3 – Photometrics Report | Download |
Manuals | Ovation Reve F-3 – CAD Files | Download |
Manuals | Ovation Reve F-3 – Acoustic Report | Download |
Other | Ovation Reve F-3 – Firmware | Download |
Ovation Rêve F-3 FAQ’s
The Rêve F-3 is designed for quiet environments. Its virtually silent operation means it won’t be picked up by microphones on set or in a theatre. It also provides completely smooth, flicker-free light, ensuring it looks perfect both to the live eye and on camera.
It produces a high-quality, soft-edged wash of light in a full spectrum of colors. Its motorized zoom allows you to easily adjust the beam from a very wide flood to a tight, narrow spot, making it versatile for covering large areas or reaching across long distances.
The fixture features an innovative adjustable yoke (the mounting bracket). This unique design allows it to be installed and positioned correctly even in areas with very low ceiling clearance where a traditional light fixture might not fit.
