COLORado Expo W
A rugged IP65-rated wash light projecting over 5,000 lumens of high-quality 3200K warm white light, featuring smooth 16-bit dimming and superior color rendering.
Perfectly suited for broadcast, theatre, trade shows, and architectural applications requiring high-quality, flicker-free warm white illumination in any environment.
-
Delivers exceptional color rendering for broadcast with a CRI of 97.9 and TLCI of 98.
-
Projects a focused wash with a 12.7° beam angle and 23.4° field angle.
-
Offers an onboard rotary dimming dial for intuitive, manual control without a console.
-
Selectable PWM provides flicker-free performance, ideal for broadcast and on-camera applications.
-
Simplifies setup by power linking up to 18 units at 230V on a single circuit.
-
Supports DMX and RDM control with four channel personalities for operational flexibility.
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
COLORado Expo W
COLORado Expo W is a rugged IP65-rated indoor/outdoor wash light that projects over 5,000 lumens of extremely high quality 3200K warm white light with a 12° beam angle. High-resolution 16-bit dimming is perfectly smooth and manually adjusting output is intuitively easy with its onboard rotary dimming dial. Phenomenal CRI and TLCI scores, selectable PWM, and included gel accessories make the COLORado Expo W a versatile instrument, on-site or on camera, in any setting.
Features
Professional Rigging Clamps
Includes professional-grade clamps, models CTC-50HC and CTC-50HCN, for secure mounting.
5-pin DMX Cables
Connect your fixtures with the included professional 5-pin DMX cables for reliable data transmission.
Complete Your Rig
Specifications
Optical
-
Light Source
1 LED (WW) 117 W, (2.187 mA), 3283 K 50,000 hours life expectancy.
-
Color Temperature (at full)
3283
-
CRI
97.9
-
TLCI
98
-
Beam Angle
12.7°
-
Field Angle
23.4°
-
Lumens
5237
-
-
Illuminance
-
Illuminance (49°)
254 lux @ 5 m
-
Illuminance (total)
2403 lux @ 5 m
-
-
Illuminance
-
Selectable PWM
600Hz, 1200Hz, 2000Hz, 2400Hz, 6000Hz, 18,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Strobe Rate
0 to 25Hz
-
Dim Modes
4
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
11.42 x 9 x 15.83 in (290 x 228 x 402 mm)
-
Weight
16.4 lb (7.4 kg)
-
Exterior Color
Black
-
Housing Material
Magnesium alloy
-
Accessory Holder/Gel Frame Size
7.5 in (190 mm)
Connections
-
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
1, 2, 3 or 4
-
Modes/Personalities
4 personalities (1ch, 2ch, 3ch, 4ch)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
8 units @ 100 V; 9 units @ 120 V; 16 units @ 208 V; 18 units @ 230 V; 18 units @ 240 V
-
Power and Current
150 W, 1.495 A @ 100 V, 60 Hz [9.6 A inrush]
-
Power and Current
149 W, 1.234 A @ 120 V, 60 Hz [7.4 A inrush]
-
Power and Current
145 W, 0.723 A @ 208 V, 60 Hz [6.4 A inrush]
-
Power and Current
145 W, 0.657A @ 230 V, 50 Hz [6.8 A inrush]
-
Power and Current
145 W, 0.633 A @ 240 V, 50 Hz [7.0 A inrush]
-
Power and Current (resting)
7 W, 0.100 A @ 100 V, 60 Hz
-
Power and Current (resting)
7 W, 0.098 A @ 120 V, 60 Hz
-
Power and Current (resting)
6 W, 0.115 A @ 208 V, 60 Hz
-
Power and Current (resting)
6 W, 0.121 A @ 230 V, 50 Hz
-
Power and Current (resting)
6 W, 0.125 A @ 240 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET, FCC, ETL, cULus, UKCA
-
IP Rating
IP65, outdoor/wet, with pressure equalizing M12 GORE valve
What's Included
- COLORado Expo W
- Seetronic Powerkon IP65 power cord
- Gel Frame
- Omega Bracket
- Warranty Card
- Quick Reference Guide
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
COLORado Expo W FAQ’s
Yes, the COLORado Expo W is designed for both indoor and outdoor use. Its rugged, all-weather construction means it can operate reliably in wet conditions, making it a dependable choice for any event, rain or shine.
Absolutely. It produces a high-quality, flicker-free warm white light that looks exceptional on camera. This ensures that skin tones and set colors appear natural and true-to-life, making it ideal for film, television, and livestreaming.
You have flexible control options. For quick and simple adjustments, you can use the easy-to-use manual dimming knob located directly on the light. For integration into a larger professional setup, it can be connected to a lighting controller for precise remote operation.
