    Maverick Force 2 SoloWash

    A powerful single-source 480W LED wash fixture offering a full CMY+CTO color mixing system, an expansive 8:1 zoom, and a versatile effects package with a rotating gobo wheel, linear prism, and frost.
    Perfectly suited for touring, theatre, and broadcast applications where lighting designers require a compact, lightweight, and feature-rich wash light that integrates seamlessly into a larger rig.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: MAVERICKFORCE2SOLOWASH

    Maverick Force 2 SoloWash

    Specifications
    		 Download
    Quick Reference Guide
    		 Download
    User Manual
    		 Download
    DMX Chart
    		 Download
    Photometrics Report
    		 Download
    2D CAD File
    		 Download
    3D CAD File
    		 Download
    Firmware
    		 Download
    Acoustic Reports
    		 Download
    Download All Resources

    Maverick Force 2 SoloWash

    SKU: MAVERICKFORCE2SOLOWASH

    A powerful single source 480W LED wash engineered to meet lighting designer demand for classic stage wash looks with the modern features LDs expect: CMY + CTO color mixing system offering a wide color palette, independent color wheel with CRI and CTB filters, expansive 8:1 zoom, rotating gobo wheel with interchangeable geometric gobos, linear 5-facet prism, and frost. Housed in a compact and lightweight design and calibrated to match the colors of other Force fixtures in the rig. Take control with DMX, RDM, sACN, Art-Net, or W-DMX.

    Features

    Compact Wash Fixture

    A fully featured, compact, and lightweight 480W single-source LED wash light.

    Variable Color Mixing

    Create a wide pallet of colors using the versatile CMY + CTO color mixing system.

    Advanced Color Wheel

    Includes CRI and CTB filters on the color wheel for added flexibility and color accuracy.

    Rotating Gobo Wheel

    Enhance your designs with a single rotating wheel featuring dynamic geometric gobos.

    Wide Zoom Range

    Adjust the beam from a narrow 6.3° to a wide 55.7° for variable coverage.

    Smooth 16-Bit Dimming

    Achieve exceptionally smooth control of fades with 16-bit resolution on the master dimmer.

    Versatile Control Protocols

    Full flexibility of control is provided through DMX, WDMX, sACN, and Art-Net compatibility.

    RDM Enabled

    Easily perform remote addressing and troubleshooting with RDM functionality.

    Beam Shaping Tools

    Further manipulate the beam with a linear 5-facet prism and a variable frost filter.

    True 1 Power Input

    Ensures a secure and reliable power connection with a True 1 compatible input.

    Easy Fixture Setup

    Utilize three setup menu presets and preset sync for quick cross-loading to multiple fixtures.

    USB Software Updates

    Keep the fixture’s software current using the convenient onboard USB slot.

    Battery Backup Display

    The display features battery backup and auto-rotates for easy viewing regardless of fixture orientation.

    Fail-Safe Ethernet Connectivity

    Data can pass through the fixture even if power is lost, ensuring signal continuity.

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Optical

      • Light Source

        1 LED (CW) 480 W (15 A), 50,000 hours life expectancy

      • Color Temperature (at full)

        7308 K

      • Color Temperature (range)

        7308 to 3007 K

      • CRI

        70.4 (with filter: 87.7)

      • Front Lens Diameter

        178 mm

      • Beam Angle

        6.3° to 32.8°

      • Field Angle

        9.3° to 49.5°

      • Cutoff Angle

        11.2° to 55.7°

      • Zoom Range

        6.3° to 55.7°

      • Lumens – Source

        39,200

      • Lumens – Output

        30,967

      • Selectable PWM

        600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 15000 Hz

      Dynamic Effects

      • Pan and Tilt

        540°/270°

      • Pan and Tilt Ranges

        540°, 360°, 180° pan/270°, 180°, 90° tilt

      • Colors

        7 + open, split colors, continuous scroll at variable speeds

      • Colors

        CMY flags, CTO flag

      • Gobos

        7 + open (7 Metal), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds

      • Dimmer

        Electronic

      • Shutter/Strobe

        Electronic

      • Zoom

        Motorized

      • Focus

        Motorized

      • Frost

        Motorized

      • Iris

        Motorized

      • Prism

        5 Facets, motorized, rotating

      • Strobe Rate

        0 to 20 Hz

      • Move-in-Black

        Yes

      • Dim Curves

        5

      Construction/Physical

      • Dimensions

        16.8 x 10.7 x 25.8 in (426 x 272 x 656 mm)

      • Weight

        53.4 lb (24.2 kg)

      • Exterior Color

        Black

      • Housing Material

        Aluminum diecast, High-impact flame-retardant polymer, Steel

      Connections

      • Power Connection

        Seetronic Powercon IP65

      • Power Input/Output

        Seetronic Powercon IP65

      • Data Connectors

        3-pin XLR, 5-pin XLR, Neutrik RJ45 Connectors in/out

      • Cable Length (power)

        5 ft (1.5 m)

      • Software Connection

        Type-C USB

      Control

      • Control Protocol

        Art-Net, sACN, RDM, DMX, W-DMX

      • DMX Channels

        21ch or 27ch

      • Art-Net/sACN Channels

        21ch or 27ch

      • Modes/Personalities

        2 personalities (21ch or 27ch)

      Electrical

      • Input Voltage

        100 to 240 VAC, 50/60 Hz (auto-ranging)

      • Power Linking

        2 units @ 120 V; 3 units @ 208 V; 3units @ 230 V

      • Power and Current

        660 W, 5.57 A @ 120 V, 60 Hz

      • Power and Current

        649 W, 3.24 A @ 208 V, 60 Hz

      • Power and Current

        641 W, 3.07 A @ 230 V, 50 Hz

      Battery

      • Battery type

        Lithium Ion

      • Rechargeable

        Yes

      • Battery Charge Time

        5 hours

      • Battery Life

        1 hours

      • Battery Power

        3.7 V, 500 mAh

      Certifications/Qualifications

      • Certifications

        CE, MET, FCC, UKCA

      • IP Rating

        IP20, dry location

        • Noise Levels
          • Idle

            32.8 dB(A) @ 1 m

          • Max

            37.4 dB(A) @ 1 m

          • Eco

            35.1 dB(A) @ 1 m

          • Auto

            36.6 dB(A) @ 1 m

          • Full

            44.2 dB(A) @ 1 m

      • Temperature (Operating)

        14 °F to 113 °F (-10 °C to 45 °C)

      Compatible Accessories

      • Clamps
      • Neutrik powerCON cables
      • Neutrik etherCON cables
      • DMX Cables
      • Flight Cases

      What's Included

      • Maverick Force 2 SoloWash
      • Seetronic Powercon IP65 power cord
      • (2) 140mm Omega brackets with mounting hardware

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Manuals
      Maverick Force 2 SoloWash – Quick Reference Guide
      		Download
      Manuals
      Maverick Force 2 SoloWash – User Manual
      		Download
      DMX
      Maverick Force 2 SoloWash – DMX Chart
      		Download
      Photometrics
      Maverick Force 2 SoloWash – Photometrics Report
      		Download
      Drawings
      Maverick Force 2 SoloWash – 2D CAD File
      		Download
      Drawings
      Maverick Force 2 SoloWash – 3D CAD File
      		Download
      Other
      Maverick Force 2 SoloWash – Firmware
      		Download
      Manuals
      Maverick Force 2 SoloWash – Acoustic Reports
      		Download

      Learn How To Use Your Maverick Force 2 SoloWash

      Explore these detailed videos showcasing setup, features, and creative applications for this product.

      • Move Forward with the Maverick FORCE Family of LED Moving Heads

        The Maverick FORCE family from CHAUVET Professional delivers a powerful combination of lighter weight and brighter output. These LED moving heads are engineered with the forward-thinking features designers demand for any live venue, theatre, or broadcast application.

      • Light Snacks: Maverick Force 2 SoloWash vs Maverick Storm 4 SoloWash

        Explore two powerhouse single-source wash fixtures from CHAUVET Professional. The Maverick Force 2 SoloWash and IP65-rated Maverick Storm 4 SoloWash combine classic wash looks with modern effects like rotating gobos, empowering bold designs for broadcast, stage, and live events.

      Video Library

      Latest Articles

      Browse Articles

      Maverick Force 2 SoloWash FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the Maverick Force 2 SoloWash
      What kind of colors and effects can the Maverick Force 2 SoloWash create?

      It offers a full spectrum of rich, customizable colors through its advanced color mixing system. For quick access, it also has a separate wheel with built-in colors. To create dynamic visual effects, it includes a rotating wheel with interchangeable patterns (gobos), a frost filter to soften the light, and a prism to split the beam into multiple projections.

      How versatile is the beam on the Maverick Force 2 SoloWash?

      The fixture is extremely versatile, featuring a wide zoom range that can be adjusted from a very tight, narrow beam to an incredibly broad wash of light. This allows you to precisely illuminate a small target or flood a large area of a stage, making it adaptable for many different lighting designs.

      Is the Maverick Force 2 SoloWash easy to set up and control?

      Yes, it’s designed for convenience. It’s relatively compact and lightweight, making it easier to handle and rig. For control, it supports all major professional methods, including wired and wireless options, ensuring seamless integration into any lighting setup. A helpful battery-powered display allows you to configure settings even when the fixture isn’t connected to main power.
