COLORado Solo Batten 4

Optical

• Light Source

  48 LEDs (8 red, 8 green, 8 blue, 8 amber, 16 white) 3 W, (612 mA) 50,000 hours life expectancy

• Color Temperature (range)

  1800 to 8000 K

• CRI (3200 K)

  77.2

• Installed Optics

  18°

• Beam Angle (Horizontal)

  18°

• • Beam Angle
    • (Horizontal w/ Filter)

      35°

    • (Vertical)

      17°

    • (Vertical w/ Filter)

      16°

• Field Angle (Horizontal)

  34°

• • Field Angle
    • (Horizontal w / Filter)

      66°

    • (Vertical)

      30°

    • (Vertical w / Filter)

      32°

• Lumens

  3,730

• Illuminance (total)

  1,270 lux @ 5 m

• Illuminance w/ Filter (total)

  432 lux @ 5 m

• Selectable PWM

  600, 1,200, 2,000, 4,000, 6,000, 25,000

Dynamic Effects

• Dimmer

  Electronic

• Shutter/Strobe

  Electronic

• Strobe Rate

  0 to 25Hz

• Standalone Color Mixing

  Yes

• Color Temperature Presets

  Yes

• Dim Modes

  5

• Built-in Automated Programs

  Yes

• Customizable Programs

  Yes

• Recall Custom Programs

  Yes

Construction/Physical

• Dimensions

  14.65 x 9.06 x 9.96 in (372 x 230 x 253 mm)

• Dimensions (shipping size)

  17.32 x 8.85 x 13.58 in (440 x 225 x 345 mm)

• Weight

  17.2 lb (7.8 kg)

• Weight (shipping weight)

  20.50 lb (9.3 kg)

• Exterior Color

  Black

• Housing Material

  Aluminum die-cast

• Accessory Holder/Gel Frame Size

  13.5 x 3.81 in (342.9 x 97 mm)

Connections

• Power Connection

  Edison (Local) plug to Seetronic Powerkon IP65

• Power Input

  Seetronic Powerkon IP65

• Power Output

  Seetronic Powerkon IP65

• Data Connectors

  5-pin IP65 XLR, Seetronic etherCON IP65

• Cable Length (power)

  5 ft (1.5 m)

Control

• Control Protocol

  Art-Net, DMX, Art-Net to DMX, sACN, RDM

• • DMX Channels
    • 1 Cell

      3, 4, 5, 8, 8, 9, 10, 10, 13, 16

    • 4 Cell

      12, 16, 20, 27, 29, 31, 35, 40, 56

• • Art-Net Channels
    • 1 Cell

      3, 4, 5, 8, 8, 9, 10, 10, 13, 16

    • 4 Cell

      12, 16, 20, 27, 29, 31, 35, 40, 56

• Modes/Personalities

  19 personalities

Electrical

• Input Voltage

  100 to 240 VAC, 50/60 Hz (auto-ranging)

• Power Linking

  13 units @ 120 V; 24 units @ 208 V; 25 units @ 230 V

• Power and Current

  114 W, 0.990 A @ 120 V, 60 Hz [4.2 A inrush]

• Power and Current

  116 W, 0.558 A @ 208 V, 60 Hz [3.60 A inrush]

• Power and Current

  116 W, 0.538 A @ 230 V, 50 Hz [2.6 A inrush]

• Power and Current (resting)

  10 W, 0.09 A @ 120 V, 60 Hz

• Power and Current (resting)

  23 W, 0.11 A @ 208 V, 60 Hz

• Power and Current (resting)

  26 W, 0.11 A @ 230 V, 50 Hz

Certifications/Qualifications

• Certifications

  CE, MET, FCC

• IP Rating

  IP65, temporary outdoor/wet use

• Temperature (Ambient)

  -4 °F to 113 °F (-20 °C to 45 °C)
