    ÉPIX Flex 20

    The ÉPIX Flex 20 is a durable, 5-meter, IP67-rated flexible LED strip featuring 240 individually controllable, pixel-mappable RGB LEDs for creating dynamic color and video effects.
    Perfect for outlining complex structures and creating immersive visual designs in permanent outdoor architectural applications, nightclubs, and other entertainment venues.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: EPIXFLEX20

    ÉPIX Flex 20

    Specifications
    		 Download
    ÉPIX Flex 20 Quick Reference Guide
    		 Download
    ÉPIX Flex 20 Connection Guide
    		 Download
    Download All Resources

    ÉPIX Flex 20

    SKU: EPIXFLEX20

    ÉPIX Flex 20 is a durable, outdoor-rated LED flexible strip that extends 5 meters and can be cut and prolonged without compromising its IP67 rating. This allows it to line even the most complicated spaces. 240 individually controllable RGB LEDs allow for a variety of color-changing options that can be dimmed and brightened as you see fit, and pixel-mapped for showing video and/or motion graphics. The unit’s reliable plug-and-play 24 V system allows for 75ft of extension between the first ÉPIX Flex 20 and the ÉPIX Flex Drive, which is required for operation and controls up to eight ÉPIX Flex 20 strips. Expect versatile control options including DMX, Art- Net and sACN (streaming ACN) and reduced programming time by tapping into alternate personalities of 17 channel or the pixel personality 720 channels) for use with video servers. 10 mounting brackets are included to ease use in a variety of permanent installations like nightclub or architectural entertainment venues.

    Features

    Flexible Outdoor LED Strip

    This pixel-mapping LED strip is flexible and rated for outdoor use, making it suitable for a wide variety of applications.

    Included Mounting Hardware

    Ten sets of mounting brackets and screws are included for secure, permanent installations.

    Multiple Control Personalities

    Choose from 17 or 34 channel modes for simplified programming or a pixel personality for direct control with video servers.

    Versatile Control Protocols

    Supports DMX, Art-Net, and sACN to easily integrate into touring, rental, or installation systems.

    RDM Enabled

    Full RDM support allows for convenient remote addressing and configuration.

    Customizable Length

    Available in 5-meter rolls that can be cut to your desired length for custom-fit installations.

    Required Power and Data Driver

    The ÉPIX Flex Drive is required to provide power and data for operation.

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

    Specifications

    Download Product Specs

    Optical

    • Light Source

      240 LEDs (tri-color RGB) SMD 50,000 hours life expectancy

    • Lumens

      140 lm/ft

    • Viewing Angle

      160°

    • Pixels

      240 x 1

    • Pixel Pitch

      20 mm

    Construction/Physical

    • Dimensions

      196.85 x 0.55 x 0.2 in (5,000 x 14 x 5 mm)

    • Weight

      1.2 lb (0.6 kg)

    • Exterior Color

      Clear

    • Housing Material

      high temperature silicone with UV protection

    Connections

    • Data Connectors

      3-pin IP65 FLEX cable

    • Physical Linking

      2 ÉPIX Flex 20 (per output) (4 total) (without ÉPIX Flex Boost); 2 additional ÉPIX Flex 20 with ÉPIX Flex Boost (per output) (8 total)

    Control

    • Control Protocol

      Art-Net, sACN, DMX

    • DMX Channels

      17, 34 or PIXEL

    • Art-Net Channels

      17, 34 or PIXEL

    Electrical

    • Power and Current

      79 W, 0.653 A @ 120 V, 60 Hz

    • Power and Current

      93 W, 0.450 A @ 208 V, 60 Hz

    • Power and Current

      95 W, 0.417 A @ 230 V, 50 Hz

    Certifications/Qualifications

    • Certifications

      CE, MET

    • IP Rating

      IP67, temporary outdoor/wet use

    • Temperature (Ambient)

      -4 °F to 113 °F (-20 °C to 45 °C)

    Required Accessories

    • Controller (required): ÉPIX Flex Drive

    Compatible Accessories

    • ArKaos Media Master Express + KN software
    • IPFLEXEXT5FT
    • IPFLEXEXT15FT
    • IPFLEXEXT25FT
    • IPFLEXEXT50FT

    What's Included

    • ÉPIX Flex 20
    • Installation kit with 10 bracket sets
    • Termination kit with end cap and silicone glue

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    Downloads

    Download All
    Manuals
    ÉPIX Flex 20 Quick Reference Guide
    		Download
    Manuals
    ÉPIX Flex 20 Connection Guide
    		Download

    ÉPIX Flex 20 FAQ’s

    Quickly find answers to common questions about setup, operation, and features of the ÉPIX Flex 20
    What is the ÉPIX Flex 20 used for?

    ÉPIX Flex 20 is a flexible, 5-meter LED strip designed for creating dynamic lighting and video effects. It’s perfect for outlining architectural features, stages, or intricate designs in both indoor and outdoor settings, as it is durable and weatherproof. Each of its 240 lights can be controlled individually to display vibrant animations, graphics, and video content.

    Can the ÉPIX Flex 20 be cut to a custom length?

    Yes, a key feature of the ÉPIX Flex 20 is that it can be cut to the exact length you need for your project. This allows for clean, custom-fit installations along complex curves and tight spaces without compromising its weatherproof qualities, making it highly versatile for creative designs.

    How do you power and control the ÉPIX Flex 20?

    The ÉPIX Flex 20 requires the separate ÉPIX Flex Drive controller to function. This drive unit powers the strip and allows you to control the lighting effects. A single drive can control multiple strips, making it easy to synchronize large, complex lighting installations and display video across them.

    If you have any inquiries about our lights, feel free to ask us or visit our help desk for more information.
