    New

    Cloud 9X IP

    A compact, IP-rated low-lying fogger that creates dense, floor-hugging fog using only tap water and specialized fluid, eliminating the need for dry ice or CO2.
    Ideal for professional touring productions, event stages, and ballrooms requiring a reliable, continuous low-fog effect without the logistical challenges of dry ice.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: CLOUD9XIP

    Cloud 9X IP

    Specifications
    		 Download
    Quick Reference Guide
    		 Download
    User Manual
    		 Download
    Download All Resources

    Cloud 9X IP

    SKU: CLOUD9XIP

    Cloud 9X IP is a compact low-lying fogger that produces high-impact floor-hugging fog ideal for stages and ballrooms. No refrigeration, dry ice or CO2 is needed, making for easy and safe operation that requires no special handling, licensing, or training.

    Cloud 9X IP creates continuous output using only LLG low-lying fog fluid and tap water (no need for distilled!). Taking full advantage of its new ability to use water from a faucet, Cloud 9X IP features a rear fitting that accepts a regular garden hose for automated refilling as water is depleted.

    With a fast five-minute heat-up time and integrated water drainage system with a durable brass fitting that withstands repeated use, Cloud 9X IP setups and cleanups are always quick, easy, and reliable. Convenient control is available in any setting or application, via full-color onboard control display, RDM, DMX, or its included wireless RF handheld remote.

    Cloud 9X IP features an upgraded housing that is not only inherently corrosion resistant, but also signficantly lighter than the previous Cloud 9 model that it replaces (total weight has been reduced from ~120lbs to ~75lbs). Its new housing is also stackable (up to 3 tall), making for easy transportation by truck, and features a removable rear cover for storing accessories, keeping everything self-contained in the unit.

    Features

    High-Impact Low-Lying Fog

    This compact, professional fogger creates a dramatic low-lying fog effect perfect for stages and ballrooms.

    Outdoor and Wet Environment Use

    Designed to be suitable for temporary use in outdoor or wet conditions.

    Continuous Operation and Large Coverage

    Delivers continuous fog output capable of covering a substantial 3,230 square foot area.

    Ultrasonic Technology

    Ultrasonic agitators combine distilled water with fog fluid to create the dense, low-lying effect.

    Integrated Touring Case

    It ships in a rugged, integrated flight case with locking casters, making it ideal for touring and rental applications.

    Flexible Control Options

    Control the unit easily via the onboard full-color display, a wireless remote, or DMX.

    Fast Cleanup System

    An integrated water drainage system simplifies the cleanup process, saving you time and effort.

    CO2 Style Effect

    Produces a CO2-style effect that lasts for several minutes before dissipating when used with LLG fluid.

    No Dry Ice or CO2 Needed

    Operates without dry ice or CO2, eliminating the need for special licensing or training.

    Simple Software Updates

    Features a convenient USB-C port for easy software uploads.

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

    Specifications

    Download Product Specs

    Dynamic Effects

    • Fan Performance

      81 cfm

    • Low Fluid Shutdown

      Yes

    Construction/Physical

      • Dimensions
        • Dimensions (without back cover)

          30 x 17.36 x 19.22 in (762 x 441 x 488.1 mm)

        • Dimensions (with back cover)

          37.72 x 17.36 x 19.22 in (958 x 441 x 488.1 mm)

    • Output Nozzle (Outer Diameter)

      4.76 in (121 mm)

    • Hose Length (Fully extended)

      11 ft (3.4 m)

    • Weight

      76.6 lb (34.75 kg)

    • Exterior Color

      Black

    • Housing Material

      Aluminum alloy, High-impact flame-retardant polymer

      • Water Tank Capacity
        • (Primary Tank)

          4.91 gal (18.6 L)

        • (Reserve Tank)

          2.41 gal (9.1 L)

        • (Total)

          7.32 gal (27.7 l)

    • Tank Capacity (Low-lying Fog Fluid)

      0.8 gal (3 l)

    • Fog Fluid Consumption

      25 mL/min (0.88 fl oz/min)

    • Fog Fluid Runtime (Fog Fluid Tank,3 L)

      2 hr

    • Water Consumption

      184.7 mL/min (6.25 fl oz/min)

    • Water Runtime (w/ Total Water Tank, 27.7 L)

      2.5 hr

    Connections

    • Power Input

      Seetronic Powerkon IP65

    • Data Connectors

      3-pin/5-pin IP rated

    • Cable Length (power)

      5 ft (1.5 m)

    • Firmware upgrades

      USB type-C

    Control

    • Control Protocol

      DMX, RDM, Wireless Remote

    • DMX Channels

      3

    • Modes/Personalities

      1 personality (3ch)

    • On-Board Control

      Yes

    • Included Remote

      Yes

    Electrical

    • Input Voltage

      120 VAC, 60 Hz

    • Input Voltage

      230 VAC, 50 Hz

    • Power and Current

      1960 W, 17.5 A @ 120 V, 60 Hz

    • Power and Current

      1281 W, 5.59 A @ 230 V, 50 Hz

    • Heat-up Time

      5 min

    • Breaker Size

      10 A, 250 V

    Certifications/Qualifications

    • Certifications

      CE, ROHS, UKCA

    • IP Rating

      IP54, temporary outdoor/wet use

    • Temperature (Ambient)

      -4 °F to 113 °F (-20 °C to 45 °C)

    Required Accessories

    • Accessories (required): Fog Fluid-LLG
    • Compatible Mounting Options: Floor Mount/Positioning only w/locking wheels

    Compatible Accessories

    • Neutrik powerKON cables
    • DMX Cables

    What's Included

    • Cloud 9 X IP
    • Seetronic Powerkon IP65 power cable
    • RF remote (2-button)
    • 2 pcs. hose clamps, 6 in (152 mm) diameter
    • Barbed hose adapter (0.5 in) (13 mm) diameter
    • Barbed hose adapter hose clamp 1 in(25 mm) diameter
    • 6ft (2m) output hose, 5 in, (130 mm) diameter
    • Removable rear cover
    • Hose coupler, 5 in (130mm) diameter
    • Floor nozzle, 5 in (130mm) diameter
    • Overfill hose (polyurethane, 6mmOD, 4mm ID, 80 in / 204 cm)
    • Quick Reference Guide

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    Downloads

    Download All
    Manuals
    Cloud 9X IP – Quick Reference Guide
    		Download
    Manuals
    Cloud 9X IP – User Manual
    		Download

    Learn How To Use Your Cloud 9X IP

    Explore these detailed videos showcasing setup, features, and creative applications for this product.

    • Light Snacks: What’s New with the Cloud 9X IP

      CHAUVET Professional introduces the new Cloud 9X IP, a compact low-lying fogger with key upgrades for rentals and live productions. Discover its lighter design, RF remote control, and integrated water reservoir, all engineered for greater flexibility and easier operation.

    Video Library

    Latest Articles

    Browse Articles

    Cloud 9X IP FAQ’s

    Quickly find answers to common questions about setup, operation, and features of the Cloud 9X IP
    What do I need to run the Cloud 9X IP fog machine?

    The Cloud 9X IP is designed for simplicity. It creates a thick, floor-hugging fog effect using only ordinary tap water and LLG low-lying fog fluid. You don’t need any dry ice, refrigeration, or CO2, which means no special handling or licensing is required.

    Can the Cloud 9X IP be used for outdoor events?

    Yes, it is built with a durable, corrosion-resistant housing that is designed for temporary outdoor and wet-weather use. It ships in a rugged, stackable flight case with wheels, making it perfect for touring, rentals, and various event locations.

    How easy is it to set up and control the Cloud 9X IP?

    Setup is quick and easy with a fast five-minute heat-up time. For added convenience, you can connect a standard garden hose for automatic water refilling. You have flexible control options, including an easy-to-use onboard display, an included wireless remote, or integration with professional DMX systems.

    If you have any inquiries about our lights, feel free to ask us or visit our help desk for more information.
