    Rogue Outcast 1 Beam

    An IP65-rated moving head beam fixture that creates intensely bright aerial effects using a 14-position color wheel, overlapping prisms, frost, and 17 static gobos.
    Perfect for outdoor tours, festivals, and large-scale events that require powerful, weather-resistant, and creative aerial beam effects.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: ROGUEOUTCAST1BEAM

    Rogue Outcast 1 Beam

    Specifications
    		 Download
    Rogue Outcast 1 Beam Quick Reference Guide
    		 Download
    Rogue Outcast 1 Beam User Manual
    		 Download
    Rogue Outcast 1 Beam CAD Drawing
    		 Download
    Rogue Outcast 1 Beam IES Files
    		 Download
    Rogue Outcast 1 Beam Photometrics Report
    		 Download
    Rogue Outcast 1 Beam DMX Chart
    		 Download
    Firmware
    		 Download
    Download All Resources

    Rogue Outcast 1 Beam

    SKU: ROGUEOUTCAST1BEAM

    Rogue Outcast 1 Beam is an IP65 moving head that outputs an intensely bright 300 W beam with 14 position color wheel individually controllable for solid and split hues. The outdoor-ready unit raises the bar in dynamic effect options with its ability to focus down to a pencil-thin 1° beam for tight aerials, overlapping 8 and 5-facet prisms, frost for even light distribution, and 17 static gobos for even more creative options. Control is over DMX and RDM.

    Features

    High-Powered Beam Fixture

    A fully featured, IP65-rated fixture equipped with a long-life USHIO 300W 6500K lamp.

    Rugged Outdoor Housing

    Features a durable housing designed to withstand the elements in temporary outdoor installations.

    Precise Pan and Tilt Movement

    Delivers fast and accurate pan and tilt functions for dynamic positioning.

    Layerable Dual Prisms

    Create complex visual effects with individually controllable and overlapping 8-facet and 5-facet prisms.

    Versatile Color Wheel

    Offers a 14-position wheel that produces both vibrant solid and split-color combinations.

    Frost Filter

    Includes an integrated frost effect to achieve soft, even light distribution.

    Narrow 1-Degree Beam

    Produces an extremely focused and tight 1-degree beam for sharp aerial effects.

    Static Gobo Wheel

    Provides 17 static gobos to create a massive visual impact with intricate patterns.

    Professional Protocol Control

    Supports both DMX and RDM protocols for flexible and comprehensive control options.

    True 1 Power Input

    Ensures a secure and reliable power connection with a True 1 compatible input.

    Latest News

    Chameleon Rental Lights Up Novi Sad for Doček with 175+ CHAUVET Professional fixtures
    Chameleon Rental illuminates Novi Sad’s architecture and concerts for the city-wide Doček festival.
    Read more
    Chameleon Rental Lights Up Novi Sad for Doček with 175+ CHAUVET Professional fixtures
    Chameleon Rental illuminates Novi Sad’s architecture and concerts for the city-wide Doček festival.
    Read more
    More Related News

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Optical

      • Light Source

        USHIO NSL-300W lamp, 8000 K, 8,000 hours life expectancy

      • Color Temperature (at full)

        7115 K

      • CRI

        73.9

      • Beam Angle

        1.2°

      • Field Angle

        2.1°

      • Illuminance (total)

        154,000 lux @ 15 m

      Dynamic Effects

      • Pan and Tilt

        540°/270°

      • Pan and Tilt Ranges

        540°, 360°, 180° pan/270°, 180°, 90° tilt

      • Colors

        14 + white, split colors, continuous scroll at variable speeds

      • Gobos

        17 + open (17 metal), continuous scroll at variable speeds

      • Dimmer

        Motorized

      • Shutter/Strobe

        Motorized

      • Focus

        Motorized

      • Frost

        Motorized

      • Prism

        5 Facets, motorized, rotating

      • Prism

        8 Facets, motorized, rotating

      • Move-in-Black

        Yes

      Construction/Physical

      • Dimensions

        16.23 x 12.2 x 23.19 in (412.2 x 310 x 589.1 mm)

      • Weight

        70.2 lb (32 kg)

      • Exterior Color

        Black

      • Housing Material

        Aluminum die-cast

      Connections

      • Power Connection

        Edison plug to Seetronic Powerkon IP65 Power Input: Seetronic Powerkon IP65

      • Power Input

        Seetronic Powerkon IP65

      • Data Connectors

        5-pin IP rated

      • Cable Length (power)

        5 ft (1.5 m)

      Control

      • Control Protocol

        DMX, RDM

      • DMX Channels

        16 or 19

      • Modes/Personalities

        2 personalities (16, 19)

      Electrical

      • Input Voltage

        100 to 240 VAC, 50/60 Hz (auto-ranging)

      • Power and Current

        451 W, 3.81 A @ 120 V, 60 Hz

      • Power and Current

        436 W, 2.09 A @ 208 V, 60 Hz

      • Power and Current

        408 W, 1.76 A @ 230 V, 50 Hz

      Certifications/Qualifications

      • Certifications

        CE, MET

      • IP Rating

        IP65, temporary outdoor/wet use

      • Temperature (Ambient)

        14 °F to 104 °F (-10 °C to 40 °C)

      Compatible Accessories

      • Professional Clamps : CTC-50HC, CTC-50HCN
      • Safety Cable: SC-07
      • DMX Cables
      • IP Rated Seetronic® Powerkon Extensions

      What's Included

      • Rogue Outcast 1 Beam
      • Seetronic Powerkon IP65 power cord
      • 2 Omega brackets with mounting hardware
      • Quick Reference Guide

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Manuals
      Rogue Outcast 1 Beam Quick Reference Guide
      		Download
      Manuals
      Rogue Outcast 1 Beam User Manual
      		Download
      Drawings
      Rogue Outcast 1 Beam CAD Drawing
      		Download
      Photometrics
      Rogue Outcast 1 Beam IES Files
      		Download
      Photometrics
      Rogue Outcast 1 Beam Photometrics Report
      		Download
      DMX
      Rogue Outcast 1 Beam DMX Chart
      		Download
      Other
      Rogue Outcast 1 Beam – Firmware
      		Download

      Learn How To Use Your Rogue Outcast 1 Beam

      Explore these detailed videos showcasing setup, features, and creative applications for this product.

      • IP65 Rogue Outcast Sneak Peek

        Go all out with the IP65-rated Rogue Outcast series from CHAUVET Professional. These rugged moving heads deliver dynamic effects and powerful output, engineered to command attention at any outdoor event.

      Video Library

      Rogue Outcast 1 Beam FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the Rogue Outcast 1 Beam
      Is the Rogue Outcast 1 Beam weatherproof?

      Yes, the Rogue Outcast 1 Beam is specifically designed for temporary outdoor use. Its rugged, weatherproof housing protects it from the elements, making it a reliable choice for festivals, concerts, and events, even in wet conditions.

      What kind of lighting effects can the Rogue Outcast 1 Beam create?

      It creates a wide variety of dynamic effects. You can project a super-sharp, pencil-thin beam for stunning aerials, use 17 different built-in patterns for visual texture, and choose from 14 solid or split colors. It also features two overlapping prisms to multiply the beam for complex looks and a frost effect to soften the light.

      What is the primary use for the Rogue Outcast 1 Beam?

      The Rogue Outcast 1 Beam is designed to produce an intensely bright and very narrow beam of light. Its main use is for creating dramatic mid-air effects that cut through the sky or stage haze, making it perfect for high-impact moments in concerts, festivals, and large-scale productions.
