    PowerStream 4 IP

    The PowerStream 4 IP is a rugged, IP65-rated power splitter that taps into a single in-line feed to provide four outputs, greatly reducing the number of cables needed on a truss.
    Its compact and durable design makes it ideal for production rental houses and for pre-rigging trusses in touring, festival, and event applications.

    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    SKU: POWERSTREAM4IP

    PowerStream 4 IP

    Specifications
    Download
    Quick Reference Guide
    Download
    Download All Resources

    PowerStream 4 IP

    SKU: POWERSTREAM4IP

    PowerStream 4 IP is an ingenious, IP65 rated splitter utilizing Seetronic PowerKon IP65 connectors. Placed in-line, it taps into up to four connections out to fixtures, allowing users to pre-rig a truss and limit the need for additional cables. Designed with production rental houses in-mind, PowerStream 4 IP is compact, rugged, and comes with multiple rigging options for hanging in your rig.

    Features

    IP65 Power Distribution

    An IP65-rated power distribution box provides one input and four outputs for reliable power management.

    Professional Grade Connectors

    Features industry-standard Seetronic PowerKon IP65 connectors for secure, weather-resistant connections.

    Simple Clamp Mounting

    An integrated M12 threaded insert allows for quick and easy mounting using standard clamps.

    Integrated Safety Rail

    A built-in rail is included for the straightforward attachment of strapping safety cables.

    Compact and Riggable Design

    The compact form factor simplifies handling and makes rigging in tight spaces effortless.

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

    Construction/Physical

    • Dimensions

      10.81 x 3.0 x 2.68 in (274.5 x 76.2 x 68.0 mm)

    • Weight

      3.0 lb (1.36 kg)

    • Exterior Color

      Black

    • Housing Material

      Aluminum alloy, Aluminum die-cast

    Connections

    • Power Input

      TRUE1 style Compatible Seetronic PowerKon IP65

    • Power Output

      TRUE1 style Compatible Seetronic PowerKon IP65

    • Power Output

      (Quantity) 4 power through

    Electrical

    • Input Voltage

      100 to 240 VAC, 50/60 Hz (auto-ranging)

    • Max Pass Through

      16A

    Certifications/Qualifications

    • Certifications

      CE, UKCA

    • IP Rating

      IP65, temporary outdoor/wet use

    Compatible Accessories

    • IP65 rated Seetronic PowerKon cables
    • Safety cables
    • Clamps with M12 threaded bolts

    What's Included

    • Power Stream 4 IP

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    Downloads

    Manuals
    Powerstream 4 IP – Quick Reference Guide
    Download

    Learn How To Use Your PowerStream 4 IP

    Explore these detailed videos showcasing setup, features, and creative applications for this product.

    • Light Snacks: IP Power Cable Management

      Improve your cable management and utilize circuit power more efficiently for IP65-rated fixtures. This tutorial demonstrates how the PowerStream 4 IP from CHAUVET Professional splits a single power feed into multiple outputs, helping you build cleaner, more reliable rigs for any all-weather production.

    PowerStream 4 IP FAQ’s

    Quickly find answers to common questions about setup, operation, and features of the PowerStream 4 IP
    What is the PowerStream 4 IP used for?

    The PowerStream 4 IP is a compact power distribution box designed to simplify your lighting setup. You connect a single main power cable to it, and it splits that power into four separate outputs. This allows you to easily provide power to multiple light fixtures on a truss or stand, dramatically reducing cable clutter and setup time.

    Can the PowerStream 4 IP be used outdoors?

    Yes, it is designed for temporary outdoor use. Its weatherproof construction protects the connections from elements like rain and dust, making it a reliable choice for outdoor events, festivals, and productions where conditions might be wet or unpredictable.

    How do you mount the PowerStream 4 IP on a lighting truss?

    The PowerStream 4 IP is built for easy and flexible mounting. It has a threaded insert for attaching a standard lighting clamp, allowing you to secure it directly to a truss. It also features a built-in rail for simple strapping, along with an attachment point for a safety cable for added security.

    If you have any inquiries about our lights, feel free to ask us or visit our help desk for more information.
