Maverick Storm 2 Profile M
A rugged, C5M marine-grade, and IP65-rated profile moving head fixture that offers enhanced corrosion resistance and a comprehensive suite of features including precise shutter framing, CMY + CTO color mixing, gobos, and effects.
Perfectly suited for permanent outdoor installations, cruise ships, theme parks, and touring applications, especially in coastal or marine environments requiring maximum protection against corrosion.
-
Features a powerful 588 W cool white LED engine with a 50,000-hour life expectancy.
-
Built with C5M marine-grade paint, aluminum construction, and a protective SunShield.
-
Delivers a versatile 5.8° to 56.1° zoom range for flexible beam shaping and coverage.
-
Offers variable CMY + CTO mixing and a color wheel with high-CRI and CTB filters.
-
Includes dual gobo wheels, a 5-facet prism, iris, and frost for dynamic effect layering.
-
Provides precise beam control with a fully rotational four-blade framing shutter system.
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
Maverick Storm 2 Profile M
With its full aluminum construction and C5M marine-grade finish, Maverick Storm 2 Profile M adds an extra layer of external corrosion resistance to an already rugged IP66 build. Internal optical components are protected by SunShield technology that comes on whenever the fixture powers down, resulting in a fully-armored fixture that also brings a full armory of features: precise shutter framing, expansive zoom, variable CMY + CTO color mixing, color wheel with CRI and CTB filters, static and rotating gobo wheels, five-facet prism, iris, and frost. A complete creative wheelhouse in a lightweight midsized powerhouse with the enhanced protection to perform extended duty in and near marine environments.
Features
Compact LED Profile Fixture
A fully featured, compact, and lightweight IP65-rated 580W LED yoke profile fixture.
Variable CMY + CTO Color Mixing
Create a wide pallet of colors with the versatile CMY and CTO color mixing system.
Rotational Framing System
A four-blade framing shutter system with full rotation allows for precise shaping of the light beam.
Advanced Color Wheel
The color wheel includes CRI and CTB filters for added color temperature and rendering flexibility.
Wide Zoom Range
A versatile 5.8° to 56.1° zoom range allows for variable beam sizes to fit any application.
Dynamic Beam Effects
Includes a 5-facet prism wheel for creating stunning aerial and surface effects.
Rotating Gobo Wheel
A fully rotating, indexing, and interchangeable gobo wheel uses a convenient slot and lock system.
Static Gobo Wheel
A second gobo wheel provides an additional selection of static patterns for layering effects.
Marine Grade Construction
Features a C5M paint process and full aluminum construction for extended use in marine environments.
Protective Display Cover
An included display cover provides extra protection for extended outdoor and marine use.
Stainless Steel Hardware
Stainless steel gland nuts ensure durability during prolonged outdoor usage near marine environments.
Smooth 16-Bit Dimming
Achieve exceptionally smooth control of fades with 16-bit dimming on the master dimmer.
RDM Control
RDM control over DMX enables remote fixture monitoring and reporting.
Total Beam Control
Shape and modify the beam with a dedicated iris, 5-facet prism, and a frost filter.
True 1 Power Input
Ensures a secure and reliable power connection with a True 1 compatible input.
Integrated Sun Shield
Protects the internal optical path from direct sunlight damage when the fixture is powered off.
Easy Setup Presets
Simplify shop setup with three menu presets and the ability to sync settings across multiple fixtures.
Battery Backup Display
Configure the fixture without main power using the battery-backed display that auto-rotates for easy viewing.
Latest News
Complete Your Rig
Specifications
Optical
-
Light Source
1 LEDs (CW) 588 W, (4.6 A), 7500 K, 50,000 hours life expectancy
-
Color Temperature (at full)
7,242 K
-
CRI
71.4
-
CRI with CRI Filter
90.3
-
Front Lens Diameter
127 mm
-
Beam Angle
6° to 42°
-
Field Angle
7.1° to 54.1°
-
Cutoff Angle
7.7° to 56.5°
-
Zoom Range
6° to 54.1°
-
Lumens – Source
43,500
-
Lumens – Output
25,840
-
-
Illuminance
-
Illuminance (6°)
70,007 lux @ 5 m
-
Illuminance (54.1°)
2,624 lux @ 5 m
-
-
Illuminance
-
Selectable PWM
600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
-
Pan and Tilt
540°/270°
-
Pan and Tilt Ranges
540°, 360°, 180° pan/270°, 180°, 90° tilt
-
Colors
7 (including CRI and CTB filters) + white, split colors, continuous scroll at variable speeds
-
Colors
CMY flags, CTO flag
-
Gobos (1)
7 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
-
Gobos (2)
9 + open (glass), continuous scroll at variable speeds
-
Gobo Size
Gobo Wheel 1 (rotating): 25.5 mm (outside), 18 mm (image), 1.1 mm (max. thickness)
-
Framing Shutters
4 Blades, each with dual axis movement, Full blackout.
-
Framing Shutter rotation
+/- 60° rotation.
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Zoom
Motorized
-
Focus
Motorized
-
Frost
Motorized
-
Iris
Motorized
-
Prism
5 Facets, motorized, rotating
-
Strobe Rate
0 to 20 Hz
-
Move-in-Black
Yes
-
Dim Curves
4
Construction/Physical
-
Dimensions
9.92 x 15.28 x 27.52 in (252 x 388 x 699 mm)
-
Weight
70.2 lb (31.9 kg)
-
Exterior Color
C5M rated (White)
-
Housing Material
Aluminum diecast, High-impact flame-retardant polymer, Steel
Connections
-
Power Connection
Termination-ready bare-ended
-
Power Input
proprietary IP65
-
Data Connection
bare wired to proprietary IP65 input cable
-
Data input/output
Termination-ready bare-ended
-
-
Cable Length
-
(Power Input)
5 ft (1.5 m)
-
(Hardwire Connection)
6.6 ft (2 m)
-
(Signal In/Out)
5 ft (1.5 m)
-
(Signal Hardwire Connection)
6.6 ft (2 m)
-
-
Cable Length
Control
-
Control Protocol
Art-Net, DMX, RDM, W-DMX, sACN
-
DMX Channels
32 or 48
-
Art-Net Channels
32 or 48
-
Modes/Personalities
2 personalities (32, 48)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power and Current
800 W, 8.20 A @ 100 V, 60 Hz
-
Power and Current
800 W, 6.82 A @ 120 V, 60 Hz
-
Power and Current
779 W, 3.77 A @ 208 V, 60 Hz
-
Power and Current
763 W, 3.41 A @ 230 V, 50 Hz
-
Power and Current
767 W, 3.34 A @ 240 V, 50 Hz
-
Breaker Size
F15 A, 250 V
Certifications/Qualifications
-
Certifications
CE, MET, FCC
-
IP Rating
IP66, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
-
Temperature (Ambient)
4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories
- Professional Clamps : CTC-50HC, CTC-50HCN
- Safety Cable: SC-08
- DMX Cables
- IP Rated Seetronic® Powerkon Extensions
- UPLOAD 08 software uploader
- Micro T-1 TRX G5 WDMX Transceiver
- FLIGHT CASE TBA
What's Included
- Maverick Storm 2 Profile (Marine)
- Omega bracket with mounting hardware ( 2 Allen Key bolts)
- Display cover
- IP5Power Extension Cable
- DMX Adapter
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
Maverick Storm 2 Profile M FAQ’s
It is specifically built to withstand harsh weather and coastal environments. The fixture features a special marine-grade finish and all-aluminum construction to resist corrosion from salt air. Its weatherproof design protects it from rain and dust, while an integrated SunShield automatically protects the internal optics from sun damage when the light is powered off.
This versatile light offers a full range of professional effects. You can create virtually any color with its advanced mixing system, project crisp patterns with rotating or static wheels, and precisely shape the beam of light. It also features a wide zoom, a prism effect to multiply the beam, and a frost filter to soften the light for total creative control.
Its main advantage is the special anti-corrosion, marine-grade finish, making it exceptionally durable for long-term use in seaside locations where salt and humidity can damage standard equipment. While being incredibly rugged and fully weatherproof, it remains a compact and feature-packed fixture, combining high performance with extreme durability.
