COLORdash Batten H12X IP
A rugged, IP65-rated linear wash batten featuring twelve individually-controllable hex-color RGBWAUV LEDs that deliver a high-output, broad color palette with pixel-mapping capabilities.
Perfect for any indoor or outdoor production, broadcast, or live event that requires a durable, all-weather linear fixture for powerful washes and dynamic eye-candy effects.
-
Delivers over 4,700 lumens of output from twelve 10W hex-color (RGBWA+UV) LEDs.
-
Provides a wide 24.9° beam angle and 40.7° field angle for broad, even wash coverage.
-
Features four selectable dimming curves and adjustable PWM for smooth, flicker-free on-camera performance.
-
Maintains an even pixel pitch between fixtures to create seamless, dynamic pixel-mapped effects.
-
Supports both DMX and RDM protocols with eight personalities for versatile control integration.
-
Offers flexible mounting with hanging brackets that double as floor stands for versatile placement.
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
COLORdash Batten H12X IP
The rugged COLORdash Batten H12X IP RGBWAUV linear wash with 12 individually-controllable hex-colored LEDs efficiently delivers a broad palette of subtle to saturated color with beautiful precision, weighing in under 18 lbs while delivering over 4,700 lumens of output. Flawlessly smooth 16-bit fades with four selectable dimming curves. Flicker-free output with multiple PWM frequencies. Maintains an even pixel pitch for perfect pixel mapped looks when used in multiples. Setup is easy with hanging brackets that double as floor stands. With RDM to remotely choose its DMX personality and an OLED display to easily read its onboard menu, COLORdash Batten H12X IP offers convenient operation and excellent performance as an IP65-rated all-weather die-cast workhorse at home in any environment, in the rig or on the floor, live or on camera, indoor or out.
Features
Versatile LED Batten
This rugged RGBWA-UV LED batten is designed for events requiring indoor and outdoor flexibility.
IP Rated Weatherproofing
Operates reliably in any weather conditions thanks to its IP rated power and DMX connections.
Flicker-Free Operation
Adjustable Pulse Width Modulation (PWM) ensures the light output is free of flickering when on camera.
Remote Device Management
RDM capability adds flexibility by allowing you to address and configure the fixture remotely.
Smooth Dimming Curves
Selectable, smooth dimming curves eliminate flicker and choppiness for seamless fades.
Intuitive OLED Display
An easy-to-read, password-protected OLED touchscreen interface allows for simple onboard control.
Advanced Optics
The advanced optical system provides exceptional color mixing and high-efficiency light output.
Flexible Mounting Options
Included floor trunions and an omega bracket allow for easy hanging and versatile placement.
Complete Your Rig
Specifications
Optical
-
Light Source
12 LEDs (RGBAW+UV) 10 W, (532 mA), 50,000 hours life expectancy
-
Color Temperature (at full)
11567 K
-
Beam Angle
24.9°
-
Field Angle
40.7°
-
Lumens
4,796 lm
-
Illuminance (total)
881 lux @ 5 m
-
Selectable PWM
600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Strobe Rate
0 to 23 Hz
-
Standalone Color Mixing
Yes
-
Color Temperature Presets
Yes/No
-
Dim Modes
4
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
39.4 x 8.129 x 3.78 in (1000 x 208 x 96 mm)
-
Weight
17.4 lb (8 kg)
-
Exterior Color
Black
-
Housing Material
Aluminum diecast
Connections
-
Power Connection
Edison (local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
3- and 5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
6, 8, 9, 13, 14, 42, 47 or 59
-
Modes/Personalities
8 personalities (6, 8, 9, 13, 14, 42, 47, 59)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
9 units @ 120 V; 16 units @ 208 V; 17 units @ 230 V
-
Power and Current
154 W, 1.284 A @ 120 V, 60 Hz
-
Power and Current
151 W, 0.741 A @ 208 V, 60 Hz
-
Power and Current
151 W, 0.667 A @ 230 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET, UKCA, FCC
-
IP Rating
IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
-
IP Rating
IP66, outdoor/wet, with pressure equalizing M12 GORE valve
-
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories
- Professional Clamps: CTC-50HC, CTC-50HCN
- Seetronic Powercon power linking cables
- 5-pin IP DMX Cables
What's Included
- Colordash Batten H12X IP
- Neutrik powerCON TRUE1 power cord
- Omega Bracket (2pc)
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
Manuals | COLORdash Batten H12XIP – Quick Reference Guide | Download |
DMX | COLORdash Batten H12X IP – DMX Chart | Download |
Manuals | COLORdash Batten H12XIP – User Manual | Download |
Other | Colordash Batten H12XIP – IES Files | Download |
Photometrics | Colordash Batten H12XIP – Photometric Report | Download |
Other | Colordash Batten H12XIP – Firmware | Download |
COLORdash Batten H12X IP FAQ’s
Yes, it is specifically designed to be an all-weather workhorse. Its rugged, weatherproof body and sealed power and data connections make it reliable for temporary outdoor events, even in wet conditions.
It creates a smooth, even wash of light over a large area. It can produce a massive range of colors, from deep, saturated hues to soft pastels, plus a true blacklight (UV) effect. The 12 LEDs can also be controlled individually to create dynamic, pixel-mapped chase effects.
Absolutely. It is designed to be completely flicker-free on camera, ensuring a clean, professional look for any video production, broadcast, or stream. It also features exceptionally smooth dimming to prevent any distracting jumps or chops in brightness.
