COLORado Solo Pod E
This high-performance, IP65-rated RGBL LED wash features integrated electronic frost, enabling instant shifts from a narrow spot to a fully homogenized, wide wash.
Engineered for touring, rental, and production, its rugged build and flexible optics deliver powerful, even color mixing for any indoor or outdoor professional application.
-
High-performance RGBL LED wash with variable electronic frost for touring, rental, and production -indoors or out
-
High-power with smooth and even color mixing
-
Variable electronic frost for beam/edge softness control
-
All environment operation with IP-rated power and DMX connections
-
Easy mounting using traditional clamps, quick connecting omega bracket, or split yoke floor stand
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
COLORado Solo Pod E
COLORado Solo Pod E is a versatile IP65-rated touring, rental, and production workhorse featuring integrated electronic Smart Frost that enables instant shifts from a narrow spot to wide washes and color block effects. Advanced optics and a high-power RGBL LED light engine are engineered to deliver fully homogenized output in both modes. 16-bit dimming and selectable PWM frequencies ensure flawless live and on-camera performance. Outdoor-rated power and data connectors allow for easy connections without proprietary cabling. Rigging and setups are fast and easy with its included omega bracket with ¼ turn adaptors and 7.5” accessory compatibility.
Features
Instant Beam Shaping
Integrated electronic frost instantly shifts the beam from a tight spot to a wide wash for dynamic, on-the-fly adjustments without mechanical parts.
Superior Color Performance
A high-power RGBL LED engine delivers fully homogenized output with smooth, even color mixing and a wide range of vibrant, high-quality hues.
All-Weather Reliability
Built for any environment, its IP65-rated housing and connections ensure dependable performance for touring, rental, and production, both indoors and out.
Flexible Rigging Options
Mount fixtures quickly and securely using the included omega bracket, traditional clamps, or an optional split yoke for fast setups in any orientation.
Flawless On-Camera Operation
Achieve perfect on-camera results with 16-bit dimming and selectable PWM frequencies that eliminate flicker for broadcast, IMAG, and streaming applications.
Specifications
Optical
-
Light Source
12 LEDs (quad-color RGBL) 180W, (1.3A), 50,000 hours life expectancy.
-
Color Temperature (range)
2800 to 8000 K
-
Color Temperature (at full)
11,550 K
-
CRI @ 3200 K
83.8
-
Beam Angle
17.1°
-
Beam Angle (E-Frost)
54.7°
-
Field Angle
30.9°
-
Field Angle (E-Frost)
128.9°
-
Lumens
8160
-
Lumens (E-Frost)
7030 Illuminance: 2673 lux @ 5 m
-
Illuminance
2673 lux @ 5 m
-
Illuminance (E-Frost)
220 lux @ 5 m
-
Selectable PWM
600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Frost
Electronic
-
Strobe Rate
0 to 25Hz
-
Standalone Color Mixing
Yes
-
Color Temperature Presets
Yes
-
Dim Modes
4
-
Dim Curves
4
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
11.14 x 8.18 x 15.96 in (283 x 208 x 405.5 mm)
-
Weight
15.8 lb (7.2 kg)
-
Exterior Color
Black
-
Housing Material
Aluminum
Connections
-
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
5-pin IP65 XLR,
-
Cable Length (power)
5 ft (1.5 m)
-
Software Connection
USB
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
1ch, 5ch1, 5ch2, 7ch, 11ch, 12ch, 13ch, 16ch or HSV
-
Modes/Personalities
9 personalities (1ch, 5ch1, 5ch2, 7ch, 11ch, 12ch, 13ch, 16ch, HSV)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
7 units @ 120 V; 12 units @ 208 V; 13 units @ 230 V
-
Power and Current
190 W, 1.59 A @ 120 V, 60 Hz
-
Power and Current
187 W, 0.93 A @ 208 V, 60 Hz
-
Power and Current
189 W, 0.86 A @ 230 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET, FCC,
-
IP Rating
IP65, outdoor/wet, with pressure equalizing M12 GORE valve
-
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories
- Professional Clamps : CTC-50HC, CTC-50HCN
- Riglink TR1 Cables
- Riglink IP DMX cables
- Ovation 7.5 Barndoor
What's Included
- COLORado Solo Pod E
- Seetronic Powerkon IP65 power cord
- Gel frame
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Complete Your Rig
Downloads
COLORado Solo Pod E FAQ’s
Yes. The COLORado Solo Pod E is IP65-rated, meaning it is fully protected against dust ingress and low-pressure water jets from any direction. It uses IP65-rated power and data connectors for safe, reliable outdoor operation.
