COLORado 2 Solo VW
An IP-rated, zoomable wash light that uses dual-color cool and warm white LEDs with silent convection cooling to produce a fully homogenized beam with superior color temperature control.
Perfect for a wide range of applications requiring a silent and reliable wash, from indoor stage and studio environments to outdoor festival productions.
-
Produces superior variable white light from 2800 K to 7000 K with a high CRI of 96.
-
Delivers a wide motorized zoom range from 4.8° to 35.5° for flexible beam shaping.
-
Built with IP-rated power and data connectors for reliable all-weather performance.
-
Offers flexible DMX and RDM control with five personalities for simplified or advanced programming.
-
Includes five selectable dimming curves for exceptionally smooth fades and programming versatility.
-
Simplifies setup with power linking for up to 23 units on a single 230 V circuit.
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
COLORado 2 Solo VW
COLORado 2 Solo VW is fitted with three dual-color CW-WW LEDs to project a beautiful and fully homogenized wash with superior color temperature control and zoom. This indoor/outdoor wash light has IP rated power and data connectors, and full convection cooling to ensure a reliable and silent performance in a wide range of applications, from stage and studio to outdoor festival productions.
Features
Professional LED Wash
A zooming variable white LED wash designed for touring, rental, and production applications both indoors and outdoors.
Variable White Color Temperature
Offers a wide color temperature range from a warm 2800 K to a cool 7000 K.
Superior Wash Quality
Delivers a completely homogenized wash with excellent color mixing and a seamless zoom.
Wide Zoom Range
Features a smooth and fast zoom that adjusts from a narrow 5° to a wide 48°.
All Environment Operation
Built for use in any environment with IP rated power and DMX connections for reliable performance.
Color Temperature Presets
Includes convenient presets for common color temperatures between 2800 K and 7000 K.
Smooth Dimming Curves
Provides selectable and smooth dimming curves to enhance programming versatility.
OLED Display
Features an easy to read OLED display with password protection for secure access to settings.
Complete Your Rig
Specifications
Optical
-
Light Source
3 LEDs (dual-color CW-WW) 35 W, (2.42A), 50,000 hours life expectancy.
-
Color Temperature (range)
2800 to 7000 K
-
Color Temperature (at full)
4565 K
-
Front lens diameters
160 mm
-
CRI
96
-
Beam Angle
4.8° to 35.5°
-
Field Angle
7.3° to 48.4°
-
Cutoff Angle
9° to 56.7°
-
-
Zoom Ranges
-
Beam Angle to Cutoff Angle
4.8° to 56.7°
-
Narrowest Beam Angle to Widest Field Angle
4.8° to 48.4°
-
-
Zoom Ranges
-
Lumens (4.8°)
1,555
-
Lumens (48.4°)
1,731
-
-
Illuminance
-
4.8°
8,744 lux @ 5 m
-
48.4°
213 lux @ 5 m
-
-
Illuminance
-
Selectable PWM
600 Hz, 1200 Hz, 2,000 Hz, 4,000 Hz, 6000 Hz, 25,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Zoom
Motorized
-
Strobe Rate
0 to 25 Hz
-
Color Temperature Presets
Yes
-
Dim Modes
5
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
8.26 x 10.7 x 15.2 in (210 x 274 x 387 mm)
-
Weight
16.0 lb (7.2 kg)
-
Exterior Color
Black
-
Housing Material
Magnesium
-
Accessory Holder/Gel Frame Size
7.5 in (190 mm)
Connections
-
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
3- and 5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
1, 4, 7 10 or 10STD
-
Modes/Personalities
5 personalities (1CH, 4CH, 7CH, 10CH, 10CH Steady)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
12 units @ 120 V; 21 units @ 208 V; 23 units @ 230 V;
-
Power and Current
127 W, 1.064 A @ 120 V, 60 Hz
-
Power and Current
125 W, 0.627 A @ 208 V, 60 Hz
-
Power and Current
123 W, 0.571 A @ 230 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET
-
IP Rating
IP65, outdoor/wet, with pressure equalizing M12 GORE® valve
Compatible Accessories
- Professional Clamps: CTC-50HC, CTC-50HCN
- Neutrik TRUE1 power linking cables
- 5-pin DMX Cables
What's Included
- COLORado 2 SOLO VW
- Seetronic Powerkon IP65 power cord
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
Manuals | COLORado 2 Solo VW – Quick Reference Guide | Download |
Manuals | COLORado 2 Solo VW – User Manual | Download |
Manuals | COLORado 2 Solo VW – Cutsheet | Download |
Drawings | COLORado 2 Solo VW – IES File | Download |
Photometrics | COLORado 2 Solo VW – Photometrics Report | Download |
Drawings | COLORado 2 Solo VW – 2D CAD File | Download |
Drawings | COLORado 2 Solo VW – 3D CAD File | Download |
Other | COLORado 2 Solo VW – Firmware | Download |
COLORado 2 Solo VW FAQ’s
The COLORado 2 Solo VW lets you create the perfect shade of white light for any occasion. You can smoothly adjust the color temperature from a warm, candle-like glow to a crisp, cool daylight. This makes it easy to match other lighting, flatter skin tones on camera, or set the perfect mood for stages and events.
Yes, it is designed for all environments. Its weatherproof construction means it can be used outdoors, even in wet conditions. Plus, its advanced cooling system has no fans, so it runs completely silent, making it ideal for noise-sensitive applications like TV studios, theaters, and livestreaming.
The motorized zoom provides excellent flexibility, allowing you to quickly change the light beam from a tight, narrow spot to a very wide, smooth flood. This is perfect for highlighting a specific person or object, or for washing an entire stage, wall, or dance floor with an even field of light.
