    W-DMX Micro T-1 TRX G6

    A compact and versatile transceiver that enables wireless DMX and RDM control by transmitting or receiving both W-DMX and CRMX signals.
    Ideal for converting individual fixtures to wireless operation or for use in mobile rigs and temporary installations where cabling is difficult or undesirable.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: MICROT1TRXG6

    W-DMX Micro T-1 TRX G6

    Specifications
    		 Download
    W-DMX Micro T-1 TRX G6 User Manual
    		 Download
    Download All Resources

    W-DMX Micro T-1 TRX G6

    SKU: MICROT1TRXG6

    Wireless Solutions Micro T-1 Transceiver works with W-DMX and CRMX enabled fixtures to generate a wireless control signal for DMX and RDM protocols. These compact devices can also be set up to transmit or receive W-DMX or CRMX signals to make any fixture or rig wireless. Backward compatible with G3, G4, G4S, and G5 series, and able to operate both W-DMX and CRMX enabled products in G4S Mode. Configurable via Bluetooth with the W-DMX Configurator app. It also features a 5V USB power supply or can be used with (4) AAA batteries for up to 4 hours in transceiver mode and 8 hours in receiver mode. Indicator LEDs easily show signal strength, battery life, and transceiver or receiver mode.





    Download the App

    ConnectFX delivers dynamic and reliable control solutions when paired with WELL CONNECT. Available for iOS® and Android in both phone and tablet versions.

    Download on the App Store
    Get it on Google Play

    Features

    Universal Protocol Compatibility

    Transmit and receive one universe of W-DMX, CRMX, and RDM protocols for wide-ranging system integration.

    Bluetooth App Control

    Easily configure the device using the W-DMX Configurator app connected via Bluetooth.

    Backward Compatibility

    Works seamlessly with previous W-DMX G3, G4, G4S, and G5 series products.

    Dual System Operation

    Operate both W-DMX and CRMX enabled products simultaneously by using the G4S Mode.

    Active Frequency Hopping

    Ensures a stable and reliable wireless connection by automatically avoiding interference.

    Flexible Power Options

    Power the unit with the included 5V USB power supply or four AAA batteries for portable use.

    Extended Battery Life

    Get up to 8 hours of operation in receiver mode or 4 hours in transceiver mode on a single set of batteries.

    At-a-Glance Status Indicators

    Integrated indicator lights provide immediate visual feedback on signal strength, battery life, and current operating mode.

    Direct Fixture Integration

    Connects directly with any Maverick or WELL series fixtures for instant wireless control.

    Universal Wireless Conversion

    Effortlessly convert any wired DMX lighting system into a fully wireless one for data transmission.

    Latest News

    Musique Xpress Lights Reflects Fearless Creativity of Tainy with CHAUVET Professional
    Richard Vicens reflects Tainy’s fearless energy with a relentless, fast-moving lighting design.
    Read more
    Musique Xpress Lights Reflects Fearless Creativity of Tainy with CHAUVET Professional
    Richard Vicens reflects Tainy’s fearless energy with a relentless, fast-moving lighting design.
    Read more
    More Related News

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Construction/Physical

      • Dimensions

        3.94 x 1.57 x 2.65 in (100 x 40 x 65 mm)

      • Weight

        1.67 lb (800 g)

      • Exterior Color

        dark gray

      • Housing Material

        High-impact flame-retardant polymer

      Connections

      • Power Connection

        5V micro USB connector (micro B) to wall wart adapter

      • Data Connectors

        5-pin XLR

      Control

      • Control Protocol

        W-DMX, CRMX, RDM

      • Frequency (operating)

        # 2.4 GHz

      • Universes per device

        1

      • Number of DMX channels

        512

      • Max universe in coexistence

        16

      • Error correction

        yes

      • DMX Fidelity

        yes

      • Adaptive Frequency Hopping

        Yes

      • W-DMX G3, G4, G4S, and G5 compatibility

        Yes

      • Standard range

        up to 650 ft (200 m)

      • Internal antenna

        Yes

      • Sensitivity (0.1% PER)

        -97 dBm

      • Modulation method

        GFSK

      Electrical

      • Input Voltage

        9 VDC 1000 mA, (external power supply: 100-230 V 50/60 Hz)

      Battery

      • Battery type

        AAA

      • Rechargeable

        No

      • Battery Life

        8 hours in receiver mode, 4 hours in transceiver mode

      Certifications/Qualifications

      • Certifications

        CE, FCC

      • IP Rating

        IP20, dry location

      • Temperature (Ambient)

        -4 °F to 113 °F (-20 °C to 45 °C)

      What's Included

      • W-DMX Micro T-1 TRX G6
      • Micro USB to wall wart adapter
      • User Manual
      • Velcro attachment strap

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Manuals
      W-DMX Micro T-1 TRX G6 User Manual
      		Download

      Learn How To Use Your W-DMX Micro T-1 TRX G6

      Explore these detailed videos showcasing setup, features, and creative applications for this product.

      • Light Snacks: Linking WDMX & Lumen Radio with the W-DMX Micro T-1 TRX G6

        Unify your wireless DMX workflow across different protocols. This CHAUVET Professional guide shows how one compact transceiver can seamlessly control both W-DMX and CRMX fixtures, simplifying your entire lighting rig.

      • Light Snacks: Wireless Control of Maverick Fixtures | W-DMX Micro T-1 TRX G6

        Learn how to achieve robust wireless control for CHAUVET Professional fixtures with the W-DMX Micro T-1 TRX G6. This tutorial demonstrates setting up the compact transceiver to transmit or receive W-DMX and CRMX signals, empowering you to operate your rig with greater freedom and less cable clutter.

      • Light Snacks: Connecting the W-DMX Micro T-1 TRX G6 to a Maverick Fixture

        Learn how to configure the versatile W-DMX Micro T-1 TRX G6 transceiver for powerful wireless DMX and CRMX control. This quick guide from CHAUVET Professional shows you how to easily link fixtures and simplify your lighting rig for fast, cable-free operation in any environment.

      Video Library

      Latest Articles

      Browse Articles

      W-DMX Micro T-1 TRX G6 FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the W-DMX Micro T-1 TRX G6
      What is the W-DMX Micro T-1 TRX G6 used for?

      This compact device makes any lighting system wireless. It can act as a transmitter to send a lighting control signal from your console, or as a receiver attached to a light fixture, eliminating the need for long data cables. Its small size makes it easy to place anywhere.

      How is the W-DMX Micro T-1 TRX G6 powered?

      It offers flexible power options. You can plug it into a wall outlet with the included USB power supply for continuous use, or go completely wireless with four standard AAA batteries. On battery power, it lasts up to 8 hours as a receiver or 4 hours as a transmitter.

      How do I set up the W-DMX Micro T-1 TRX G6?

      Setup is easy using a smartphone app that connects to the device via Bluetooth. The unit also has simple indicator lights to show signal strength, battery life, and whether it is sending or receiving a signal. It is built to work with a wide range of wireless lighting products.
