    COLORdash PAR H12X IP

    The COLORdash PAR H12X IP is a rugged, lightweight, and high-output IP65-rated RGBWAUV LED wash light delivering a broad color palette with smooth, flicker-free dimming.
    This versatile, die-cast workhorse is ideal for any indoor or outdoor application, whether live or on camera, placed in a rig or on the floor.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: COLORDASHPARH12XIP

    COLORdash PAR H12X IP

    Specifications
    		 Download
    Quick Reference Guide
    		 Download
    COLORdash Par H12XIP-Standard Optics-IES Files
    		 Download
    2D CAD
    		 Download
    3D CAD
    		 Download
    User Manual
    		 Download
    Photometrics
    		 Download
    DMX Chart
    		 Download
    Firmware
    		 Download
    Download All Resources

    COLORdash PAR H12X IP

    SKU: COLORDASHPARH12XIP

    The rugged COLORdash PAR H12X IP RGBWAUV LED wash efficiently delivers a broad palette of subtle to saturated color with beautiful precision, weighing in under 12 lbs while delivering over 4,500 lumens of output. Flawlessly smooth 16-bit fades with four selectable dimming curves. Flicker-free output with multiple PWM frequencies. Punch up a hot pink, mix a delicate pastel, pick a perfectly calibrated Kelvin color temperature, or trigger intense strobe effects. With RDM to remotely choose its DMX personality and an OLED display to easily read its onboard menu, the COLORdash PAR H12X IP offers convenient operation and excellent performance as an IP65-rated all-weather die-cast workhorse at home in any environment, in the rig or on the floor, live or on camera, indoor or out.

    Features

    Versatile Indoor/Outdoor Wash Light

    A rugged RGBWA-UV LED wash light designed for flexible use in both indoor and outdoor event settings.

    IP Rated Weatherproof Design

    Features IP rated power and DMX connections, ensuring reliable operation in all weather conditions.

    Flicker-Free On Camera

    Adjustable Pulse Width Modulation (PWM) eliminates flickering, making it ideal for broadcast and video recording.

    Remote Device Management

    Includes RDM for remote addressing and troubleshooting, offering enhanced operational flexibility.

    Smooth Dimming Curves

    Selectable dimming curves ensure smooth, flicker-free fades without any choppiness.

    Advanced OLED Touchscreen

    An easy-to-read OLED display with a password-protected touchscreen interface allows for simple configuration.

    Advanced Optics

    Its advanced optical system delivers exceptional color mixing and high-efficiency light output.

    Flexible Mounting Options

    A double-bracketed yoke with an included omega bracket also functions as a floor stand for versatile placement.

    Latest News

    Behind the Scenes at Ultra Music Festival’s UMF Radio stage
    The Gravitate Productions crew reveals the all-weather rig behind Ultra Music Festival’s UMF Radio stage.
    Read more
    Behind the Scenes at Ultra Music Festival’s UMF Radio stage
    The Gravitate Productions crew reveals the all-weather rig behind Ultra Music Festival’s UMF Radio stage.
    Read more
    More Related News

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Optical

      • Light Source

        12 LEDs (hex-color RGBAW+UV) 120 W, (512 mA), 50,000 hours life expectancy

      • Color Temperature (range)

        2800 to 10,000 K

      • Color Temperature (at full)

        11,008 K

      • Beam Angle

        22.2°

      • Field Angle

        36.9°

      • Lumens

        4,532

      • Illuminance (total)

        1,052 lux @ 5 m

      • Selectable PWM

        600, 1.2k, 2k, 4k, 6k, 25k Hz

      Dynamic Effects

      • Dimmer

        Electronic

      • Shutter/Strobe

        Electronic

      • Strobe Rate

        0 to 20 Hz

      • Standalone Color Mixing

        Yes

      • Color Temperature Presets

        Yes

      • Dim Modes

        4

      • Built-in Automated Programs

        Yes

      Construction/Physical

      • Dimensions

        9.1 x 12 x 9.8 in (232 x 305.4 x 247.9 mm)

      • Weight

        11.8 lbs (5.4 kg)

      • Exterior Color

        Black

      • Housing Material

        Aluminum alloy, Aluminum die-cast

      • Accessory Holder/Gel Frame Size

        8.75 in (222 mm)

      Connections

      • Power Connection

        Edison (Local) plug to Seetronic Powercon IP65

      • Power Output

        Seetronic Powercon IP65

      • Data Connectors

        3 and 5-pin IP65 XLR

      • Cable Length (power)

        5 ft (1.5 m)

      Control

      • Control Protocol

        DMX, RDM

      • DMX Channels

        6ch ,8ch ,9ch ,13ch, or 14ch

      • Modes/Personalities

        5 personalities (6ch ,8ch ,9ch ,13ch, or 14ch)

      Electrical

      • Input Voltage

        100 to 240 VAC, 50/60 Hz (auto-ranging)

      • Power Linking

        11 units @ 120 V; 19 units @ 208 V; 21 units @ 230 V

      • Power and Current

        126 W, 1.041 A @ 120 V, 60 Hz

      • Power and Current

        123 W, 0.604 A @ 208 V, 60 Hz

      • Power and Current

        123 W, 0.547 A @ 230 V, 50 Hz

      Certifications/Qualifications

      • Certifications

        CE, MET, FCC, UKCA

      • IP Rating

        IP65, temporary outdoor/wet use

      • Temperature (Ambient)

        -4 °F to 113 °F (-20 °C to 45 °C)

      Compatible Accessories

      • Professional Clamps: CTC-50HC, CTC-50HCN
      • Seetronic Powercon power linking cables
      • 5-pin IP or Non-IP DMX Cables

      What's Included

      • Colordash Par H12XIP
      • Seetronic powercon IP65 power cord
      • Gel frame
      • Omega bracket

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Manuals
      Colordash Par H12XIP – Quick Reference Guide
      		Download
      Other
      COLORdash Par H12XIP-Standard Optics-IES Files
      		Download
      Other
      COLORdash Par H12X IP – 2D CAD
      		Download
      Other
      COLORdash Par H12X IP – 3D CAD
      		Download
      Manuals
      COLORdash PAR H12X IP – User Manual
      		Download
      Photometrics
      COLORdash Par H12X IP – Photometrics
      		Download
      DMX
      COLORdash Par H12X IP – DMX Chart
      		Download
      Other
      COLORdash PAR H12X IP – Firmware
      		Download

      Learn How To Use Your COLORdash PAR H12X IP

      Explore these detailed videos showcasing setup, features, and creative applications for this product.

      • #bts with Gravitate Productions at ULTRA Music Festival’s Radio Stage

        Gravitate Productions explains why they chose CHAUVET Professional for the ULTRA Music Festival Radio Stage. See how our IP65-rated fixtures deliver powerful, weather-resistant performance for the world’s most demanding outdoor events.

      • #bts with Charles Brennan of Gravitate Productions at the ULTRA Radio Stage

        Go behind the scenes at Ultra Music Festival with lighting programmer Charles Brennan. See how CHAUVET Professional Maverick Storm IP65 fixtures deliver powerful, weather-proof performance, ensuring the show continues rain or shine on the massive UMF Radio stage.

      Video Library

      COLORdash PAR H12X IP FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the COLORdash PAR H12X IP
      Is the COLORdash PAR H12X IP weatherproof for outdoor use?

      Yes, this light is built to be used outdoors in any weather. It’s ruggedly designed and sealed against dust and water, making it perfect for concerts, events, or architectural lighting, even in the rain. Both the power and control connections are also weather-rated for safe and reliable outdoor performance.

      What kind of colors can the COLORdash PAR H12X IP produce?

      It creates a massive spectrum of colors using its special six-color LEDs (Red, Green, Blue, Amber, White, and UV). This allows you to mix everything from deep, saturated colors to delicate pastels. It can also produce true white light in various temperatures (warm to cool) and even create ‘blacklight’ effects with its UV light for incredible versatility.

      If you have any inquiries about our lights, feel free to ask us or visit our help desk for more information.
