    onAir Producer

    The onAir Producer is a remote control system providing complete handheld access to your lighting fixtures’ controls, with the ability to save and transfer custom presets.
    Perfect for film, video, and broadcast production environments where rapid, remote fixture adjustment and consistent preset recall are essential.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    Specifications
    		 Download
    Quick Reference Guide
    		 Download
    CAD File
    		 Download

    onAir Producer

    SKU: ONAIRPRODUCER

    Customize and operate seamlessly with the onAir Producer. No matter where you need to position your fixtures, have all their on board control capability in the palm of your hand! The onAir Producer also features the ability to save your presets so you can easily transfer them from fixture to fixture or save them for your next shoot.

    Features

    Remote Fixture Control

    This handheld tool allows you to view, manipulate, and manually control all functions of out-of-reach onAir fixtures.

    Preset Management

    Download and upload user presets between compatible fixtures or store them for future use.

    Clear OLED Display

    An easy-to-read OLED display provides all the same information as the fixture’s own screen.

    Standard XLR Connection

    Connect the controller to any fixture using a standard 5-pin XLR cable.

    USB-C Recharging

    The included USB-C cable enables quick recharging from any standard USB power source.

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

    Specifications

    Download Product Specs

    Dynamic Effects

    • Dimmer

      Yes

    • Standalone Color Mixing

      Yes

    • Color Temperature Presets

      Yes

    • Green+/-

      Yes

    • Hue/Saturation/Value

      Yes

    • Built-in Automated Programs

      Yes

    Construction/Physical

    • Dimensions

      4.31 x 2.76 x 1. in (109.5 x 70 x 49 mm)

    • Weight

      0.8 lb. (0.4 kg)

    • Exterior Color

      Black

    • Housing Material

      Aluminum alloy

    Connections

    • Power Input

      USB-C Male

    • Data Connectors

      5-pin XLR

    Electrical

    • Power and Current

      4 W, 0.061 A @ 100 V, 60 Hz

    • Power and Current

      4 W, 0.056 A @ 120 V, 60 Hz

    • Power and Current

      5 W, 0.035 A @ 208 V, 60 Hz

    • Power and Current

      5 W, 0.038 A @ 230 V, 50 Hz

    • Power and Current

      5 W, 0.037 A @ 240 V, 50 Hz

    Battery

    • Battery type

      Lithium Ion

    • Rechargeable

      Yes

    • Battery Power

      3.7 V, 1,200 mAh

    Certifications/Qualifications

    • Certifications

      CE

    • IP Rating

      IP20, dry location

    Required Accessories

    • DMX Cables

    Compatible Accessories

    • DMX Cables

    What's Included

    • onAir Producer
    • USB-C Charging Cable

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    Downloads

    Download All
    Manuals
    onAir Producer – Quick Reference Guide
    		Download
    Drawings
    onAir Producer – CAD File
    		Download

    onAir Producer FAQ’s

    Quickly find answers to common questions about setup, operation, and features of the onAir Producer
    What is the onAir Producer used for?

    The onAir Producer is a handheld remote that gives you full control over your onAir lights. It’s designed for situations where the light fixture is mounted in a hard-to-reach place, like on a high ceiling or grid, allowing you to easily adjust settings from the ground.

    If you have any inquiries about our lights, feel free to ask us or visit our help desk for more information.
