    Amhaze Stadium

    The Amhaze Stadium is a tour-ready, professional water-based haze machine providing powerful output with a rapid 30-second heat-up time and adjustable control, all housed in a durable road case.
    Ideal for large-scale touring, productions, and events that demand a robust, high-output haze effect capable of withstanding the rigors of the road.

    Read More Read Less
    Read More Read Less
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    Amhaze Stadium Quick Reference Guide
    		 Download
    Amhaze Stadium User Manual
    		 Download
    Amhaze Stadium CAD Files
    		 Download

    Amhaze Stadium

    SKU: AMHAZESTADIUM

    Amhaze Stadium is a tour-ready professional water-based haze machine ideal for large-scale applications. With an output of 157 cfm, the Amhaze Stadium boasts an impressive 30-second heat-up time. It also features a durable, low-profile road case to survive the rigors of touring and production. The output and speed of haze can be easily adjusted via DMX or the LCD screen, and the unit comes equipped with an M12 threaded insert for hanging.

    Features

    Rapid Heat Up

    A 30-second heat-up time nearly eliminates any wait for operation.

    Directional Haze Flow

    The adjustable vent louver allows for precise control over the direction of the haze.

    Tour Ready Design

    Built for the road with a rugged case and an M12 threaded rigging insert for easy mounting.

    Efficient Fluid Consumption

    Run the machine for up to 11 hours on a single fluid container due to its efficient design.

    Versatile Output Control

    Achieve continuous variable haze output and blower speed via DMX or manual knobs.

    Latest News

    THAT Tent at Bonnaroo Shines with CHAUVET Professional Fixtures from Harford Sound
    Harford Sound deployed a versatile rig to light the iconic THAT tent at Bonnaroo.
    Read more
    Stifel Theatre Creates Modern System in Historic Structure with CHAUVET Professional
    St. Louis’s historic Stifel Theatre balances preservation and performance with a modern lighting rig.
    Read more
    Great Gentse Feesten For CHAUVET Professional
    A massive array of fixtures illuminated Belgium’s historic Gentse Feesten festival.
    Read more
    Chameleon Rentals and CHAUVET Professional Create Intense Mix For Green Love Festival
    Chameleon Rentals creates an immersive visual universe for Serbia’s Green Love techno festival.
    Read more
    THAT Tent at Bonnaroo Shines with CHAUVET Professional Fixtures from Harford Sound
    Harford Sound deployed a versatile rig to light the iconic THAT tent at Bonnaroo.
    Read more
    Stifel Theatre Creates Modern System in Historic Structure with CHAUVET Professional
    St. Louis’s historic Stifel Theatre balances preservation and performance with a modern lighting rig.
    Read more
    Great Gentse Feesten For CHAUVET Professional
    A massive array of fixtures illuminated Belgium’s historic Gentse Feesten festival.
    Read more
    Chameleon Rentals and CHAUVET Professional Create Intense Mix For Green Love Festival
    Chameleon Rentals creates an immersive visual universe for Serbia’s Green Love techno festival.
    Read more
    More Related News

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

    Specifications

    Download Product Specs

    Dynamic Effects

    • Fan Speed

      157 cfm

    • Low Fluid Shutdown

      Yes

    Construction/Physical

    • Dimensions

      20.60 in (523.42 mm) x 10.80 in (274.9 mm) x 15.97 (405.7 mm)

    • Weight

      38.4 lb (17.4 kg)

    • Threaded Bolt

      M12

    • Exterior Color

      Black

    • Tank Capacity

      1.3 gal (4.92l)

    • Fluid Consumption

      9.5 ml/min (0.15 gallons/hour)

    • Maximum Run time

      >8.25 hours @ full volume

    Connections

    • Power Connection

      Edison (local) plug to Seetronic Powerkon IP65

    • Power Input

      Seetronic Powerkon IP65

    • Data Connectors

      3- and 5-pin XLR

    • Cable Length (power)

      5 ft (1.5 m)

    Control

    • Control Protocol

      DMX

    • DMX Channels

      2

    • Modes/Personalities

      1 personality

    • On-Board Control

      Yes

    Electrical

    • Input Voltage

      120 VAC, 50/60 Hz or 230 VAC, 50 Hz

    • Power and Current

      1,230 W, 10.25 A @ 120 V, 50/60 Hz

    • Power and Current

      2,430 W, 10.56 A @ 230 V, 50 Hz

    • Heat-up Time

      30 sec

    Certifications/Qualifications

    • Certifications

      CE, MET, RCC, RoHS

    • MET Listing Number

      E115095

    • US Safety

      UL 499

    • Canadian Safety

      CSA C22.2 No. 64-10

    • IP Rating

      IP20, dry location

    • Minimum distance from flammable material to all exterior surfaces of the product

      3.3 ft (1 m)

    • Maximum exterior surface temperature (Tc)

      127 °F (53 ℃)

    Required Accessories

    • Compatible Mounting Options: M12 Bolt/Clamp
    • PHF5L Haze Fluid

    Compatible Accessories

    • Clamps
    • Neutrik® powerCON® cables
    • DMX Cables

    What's Included

    • Amhaze Stadium
    • Seetronic Powerkon IP65 power cord
    • Warranty Card
    • Quick Reference Guide or User Manual

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    Downloads

    Download All
    Manuals
    Amhaze Stadium Quick Reference Guide
    		Download
    Manuals
    Amhaze Stadium User Manual
    		Download
    Manuals
    Amhaze Stadium CAD Files
    		Download

    Learn How To Use Your Amhaze Stadium

    Explore these detailed videos showcasing setup, features, and creative applications for this product.

    • Amhaze Stadium Product Video by CHAUVET Professional

      Fill large-scale venues with the powerful, tour-ready Amhaze Stadium from CHAUVET Professional. Housed in a rugged road case, this water-based hazer delivers massive output with a rapid 30-second heat-up time, providing the perfect atmospheric foundation for concerts, events, and major productions.

    Video Library

    Amhaze Stadium FAQ’s

    Quickly find answers to common questions about setup, operation, and features of the Amhaze Stadium
    How fast is the Amhaze Stadium ready to use?

    The Amhaze Stadium is ready to produce haze in just 30 seconds, virtually eliminating any waiting time so your event can start on schedule.

    Is the Amhaze Stadium built for touring and travel?

    Yes, it is specifically designed for the demands of touring. The Amhaze Stadium is built into a rugged road case, making it durable and easy to transport between events and venues.

    How can I control the haze effect with the Amhaze Stadium?

    You have flexible control over the haze. The amount and speed of the haze can be precisely adjusted using either a DMX controller or the simple manual knobs on the unit. It also features an adjustable vent to direct the haze exactly where you need it.
