Rogue Outcast 2X Wash

Rogue Outcast 2X Wash is a lightweight IP65 wash that goes wide and hangs anywhere, with a wide zoom range of 8° to 66°, wide 2800 to 10000 K color temp range, wide selection of simple to complex DMX personalities, and a durable alloy housing that suits this versatile workhorse to the widest range of both indoor and outdoor applications, including on-camera use with its user selectable calibrated white. 19 bright 25W RGBW quad-LEDs occupy 5 pixel-mappable zones and produce excellent color blending and fades with 16-bit master and individual dimming.

Book a Demo


At a Glance

  • Fully featured IP65 rated RGBW LED yoke wash fixture

  • Durable and lightweight aluminum/magnesium alloy body

  • Smooth fades with 16-bit individual color and master dimming

  • 8° to 66° zoom

  • 19 RGBW LEDs, 25W each

  • 5-pin DMX input/output connections

  • 5 zones of LED control for pixel mapping control

  • Fast, smooth pan and tilt movement

  • RDM enabled for remote addressing and trouble shooting

  • Selectable PWM options for camera operation

  • User selectable calibrated white, 7500K default calibration

  • 6 distinct dimming modes for advanced control

  • Easy to read OLED display with simple, effective menu options

  • Simple and complex DMX channel profiles for programming versatility

  • USB-C port for uploading software

Specifications

Optical

  • Light Source: 19 LEDs (quad-color RGBW) 25 W, (1.5 A), 50,000 hours life expectancy
  • Color Temperature (range): 2800 to 10000 K
  • Beam Angle: 8° to 36.1°
  • Field Angle: 11.8° to 53°
  • Cutoff Range: 17.5° to 66.1°
  • Zoom Range: 8° to 66.1°
  • Lumens – Source: n/a
  • Lumens – Output: 6,258
  • Illuminance (11.8°): 8,713 lux @ 5 m
  • Illuminance (53°): 694 lux @ 5 m
  • Selectable PWM: 600Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

Dynamic Effects

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Strobe Rate: 0 to 20 Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Curves: 6
  • Built-in Automated Programs: Yes
  • Customizable Programs: No
  • Recall Custom Programs: No

Construction / Physical

  • Dimensions: 11.92x8.58x14.1" (303x218x361mm)
  • Weight: 23.4 lb (10.6 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum/magnesium alloy, High-impact flame-retardant polymer

Connections

  • Power Connection: Bare ended to Seetronic IP65 PowerKon
  • Power Input: Seetronic IP65 PowerKon
  • Power Output: Seetronic IP65 PowerKon
  • Data Connectors: 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: DMX, RDM
  • DMX Channels: 15, 17, 22, 33, 54, or 56
  • Modes/Personalities: 8 personalities (15CH, 17CH, 22CH, 33CH, 33CH MS, 54CH, 54CH MS or 56CH)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 5 units @ 120 V; 9 units @ 208 V; 10 units @ 230 V
  • Power and Current: 291 W, 2.47 A @ 120 V, 60 Hz
  • Power and Current: 284 W, 1.41 A @ 208 V, 60 Hz
  • Power and Current: 282 W, 1.28 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET, FCC, UKCA
  • IP Rating: IP65 (temporary wet location)
  • Noise Level (Idle): 0.9 dB(A) @ 1 m
  • Noise Level (Max): 42.6 dB(A) @ 1 m
  • Noise Level (Full): 44.5 dB(A) @ 1 m
  • Noise Level (Eco): 27.8 dB(A) @ 1 m
  • Noise Level (Auto): 27.7 dB(A) @ 1 m

What's Included

  • Rogue Outcast R2X Wash IP
  • Seetronic® powerCON® power cord

Optional Accessories

  • Professional Clamps: CTC-50HC, CTC-50HCN
  • Safety Cable: SC-07
  • Seetronic IP65 PowerKon cables
  • DMX Cables
  • Flight Case:CP6CASER2W
