Maverick MK3 Profile

Maverick MK3 Profile features a searing output of over 51,000 source lumens and an advanced, 4-blade shutter frame system with the ability to fully blackout and a 120° rotation. Its precision LED optics feature CMY + CTO color mixing and a fast 9:1 zoom ratio that maintains a flat field of focus even when fully wide. It also has an adjustable CRI from 74 to 93 CRI for use as a key light for broadcasted events. Maverick MK3 Profile offers great static, rotating, and animation effects from its 2 gobo wheels (1 rotating, 1 static), animation wheel, 2 independent and overlapping prisms and 2 frost options: superlight and medium. Control as you see fit with DMX, sACN, Art-Net or W-DMX.


At a Glance

  • Fully featured 820 W LED yoke profile fixture including CMY+CTO color mixing, a four blade framing shutter system with rotation, a color wheel, a CRI filter, animation wheel, a 9:1 zoom, two independently layerable prisms, two frosts, a static and a rotating gobo wheel

  • 16-bit dimming of master dimmer for smooth control of fades

  • Variable CMY + CTO color mixing system to create a wide pallet of colors

  • Independently layerable 5 facet linear and 5 facet round prisms for increased prism options

  • One rotating and one static gobo wheel for dynamic texture possibilities

  • Independent light and medium frosts for beam control

  • + or – 60 degree rotation framing shutter system to allow for better framing positioning.

  • Animation wheel for enhanced visual effects

  • Iris for total beam control

  • RDM control over DMX for fixture reporting

  • 5.9° to 64.1° zoom range for variable beam sizes

  • 3 menu presets and preset cross load for decreased shop setup time

  • True 1 compatible power input

  • Battery backup display with auto-rotate depending on fixture orientation

Specifications

Optical

  • Light Source: 1 LEDs (CW) 820 W, (24 A), 7,258 K, 50,000 hours life expectancy
  • Color Temperature (at full): 7,441 K
  • Front lens diameter: 147 mm
  • CRI: 74.1
  • CRI W / Filter: 91.2
  • TLCI: 50.9
  • Beam Angle: 5.9° to 52.7°
  • Field Angle: 7.6° to 61.4°
  • Zoom Range: 5.9° to 64.1°
  • Cutoff Angle: 8.1° to 64.1°
  • Lumens – Source: 51,000
  • Lumens – Output: 23,000
  • Illuminance (5.9°): 58,869 lux @ 5 m
  • Illuminance (52.7°): 1,860 lux @ 5 m
  • Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 15000 Hz

Dynamic Effects

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colors: 6 + white, split colors, continuous scroll at variable speeds
  • Colors: CMY flags, CTO flag, CRI filter, color correction
  • Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobos (2): 9 + open (9 glass), continuous scroll at variable speeds
  • Effect Wheel: 1 effect
  • Framing Shutters: Yes
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Focus: Motorized
  • Frost 1: Light Frost - Motorized
  • Frost 2: Medium Frost - Motorized
  • Iris: Motorized
  • Prism: 5 linear facets, motorized, rotating
  • Prism: 5 Circular facets, motorized, rotating
  • Strobe Rate: 0 to 25 Hz
  • Move-in-Black: Yes
  • Dim Curves: 5

Construction / Physical

  • Dimensions: 16.10 x 12.20 x 29.43 in (409 x 310 x 748 mm)
  • Weight: 76.4 lb (34.7 kg)
  • Exterior Color: Black
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Data Connectors: 3- and 5-pin XLR, Amphenol XLR Net RJ45 connectors in/out
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: Art-Net, DMX, W-DMX, sACN, RDM
  • DMX Channels: 38 or 54
  • Art-Net Channels: 38 or 54
  • Modes/Personalities: 2 personalities (38, 54)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 1,230 W, 10.34 A @ 120 V, 60 Hz
  • Power and Current: 1,190 W, 5.81 A @ 208 V, 60 Hz
  • Power and Current: 1,180 W, 5.24 A @ 230 V, 50 Hz
  • Power and Current (resting): 120 W, .98 A @ 120 V, 60 Hz
  • Power and Current (resting): 126 W, .60 A @ 208 V, 60 Hz
  • Power and Current (resting): 127 W, .55 A @ 230 V, 50 Hz
  • Breaker Size: F20 A, 250 V

Certifications / Qualifications

  • CE, MET, FCC
  • IP Rating: IP20, dry location
  • Noise Level (ambient): 36.5 dB level @ 1 m
  • Noise Level (Full): 62.1 dB level @ 1 m
  • Noise Level (Eco): 43 dB level @ 1 m
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included

  • Maverick MK3 Profile
  • Seetronic Powerkon IP65 power cord
  • 2 Omega brackets with mounting hardware
  • Quick Reference Guide

Optional Accessories

  • Professional Clamps: CTC-50HC, CTC-50HCN
  • Safety Cable: SC-07
  • IP Rated Seetronic® Powerkon Extensions
  • DMX cables
  • Flight Case: TBA
  • Upload 08 software uploader
